ecostore Premium 2 Door Digital Freezer, 1430lt (-22/-15) R290 Class C - UK Plug (COD 725504)
Where to buy
ecostore Premium2 Door Digital Freezer, 1430lt (-22/-15) R290 Class C - UK Plug
ecostore Premium 670 - 1430 liters Digital Freezers (R290)

ecostore Premium
2 Door Digital Freezer, 1430lt (-22/-15) R290 Class C - UK Plug

COD 725504

Where to buy
Register your product

Specifications

  • Number and type of grids (included): 8 - GN 2/1

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.7 kW

  • Net Volume: 1160 lt

    Door hinges:

    External dimensions, Width: 1441 mm

    External dimensions, Depth: 835 mm

    External dimensions, Depth with Doors Open: 1480 mm

    External dimensions, Height: 2050 mm

    Number and type of doors: 4x1/2 Full

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Internal panels material: 304 AISI

    Number of positions & pitch: 44; 30 mm

    Gross capacity: 1430 lt

    Type of model (EU Reg. 2015/1094): vertical frozen

  • Control type: Digital

    Refrigeration power at evaporation temperature: -30 °C

    Operating temperature min.: -22 °C

    Operating temperature max.: -15 °C

    Operating mode: Ventilated

  • Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 947 W

    Energy Class (EU Reg. 2015/1094): C

    Yearly and daily energy consumption (EU Reg. 2015/1094): 3500kWh/year - ISO 9001; ISO 14001kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 48.69

Product Features

Main Features

Freezer model has operating temperatures that can be adjusted from -22 to -15 °C.
Performance guaranteed at ambient temperatures of +40°C (Climatic class 5).
Large digital white-digit display with cabinet temperature display and setting. Bluetooth technology included allows to keep HACCP historical data and download them through the app.
Cabinet fitted with up to 75 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
Large digital white-digit display with cabinet temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Digital control panel allowing the easy and precise setting and control of the internal temperature.
Optiflow: back to front forced air flow and removable air conveyors provide even temperature distribution and fast cooling in any conditions.
Easy serviceability thanks to the intuitive control panel with remote access via app.
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to 30 days of event are kept in memory.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.
Rilsan coated grids for improved protection.

Sustainability

Frost Watch Control: fully automatic defrost starts only when ice is actually building-up in the evaporator and adapt the defrosting duration to guarantee perfect ice removal while optimizing energy efficiency consumption.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
CFC and HCFC-free insulation.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning
Interior LED light to save energy and for best internal visibility.

Construction

Constructed from the highest quality AISI 304 Stainless steel.
Interior base with rounded corners, pressed from a single sheet.
The rounded internal corners, the easily removable runners, grids and air conveyors allow for ease of cleaning and high hygiene standards.
Anti-corrosion bottom avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Easy access to the main components for maintenance.
Lockable door.
Mounted on wheels.
Delivered with UK plug.

Included Accessories

Quantity
Code
Description
Quantity: 8
Code: 881020
Quantity: 1
Code: 881294
