Digital Undercounter Freezer Counter - 3 Door (R290) with upstand and with cooling unit right (COD 714961)

Compare Where to buy

ecostore HP Freezer Counters - 3 comp. with top

Digital Undercounter
Freezer Counter - 3 Door (R290) with upstand and with cooling unit right

COD 714961

1-door and 4-drawer Freezer Counter, -22-15°C, AISI 304 (R290) with splashback and right cooling unit

Compare

Where to buy

Product registration

Specifications

Electric

Supply voltage: 220-240 V/1 ph/50 Hz

Electrical power max.: 0.49 kW

Compressor power: 3/4 hp
Key Information

Net Volume: 187.2 lt

N° of doors:

External dimensions, Width: 1799 mm

External dimensions, Depth: 700 mm

External dimensions, Height: 950 mm

Internal Dimensions, Width: 1252 mm

Internal Dimensions, Depth: 560 mm

Internal Dimensions, Height: 500 mm

Net weight: 137 kg

Shipping volume: 1.54 m³

Depth with doors open: 1310 mm

Gross capacity: 400 liter
Refrigeration Data

Control type: Digital

Min/Max internal humidity: /

Operating temperature min.: -15 °C

Operating temperature max.: -22 °C

Operating mode: Ventilated

Insulation: 0 mm (Cyclopentane)
ISO Certificates

ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Type reference/certification group: H6NBT3BHC
Sustainability

Refrigerant type: R290

GWP Index: 3

Refrigeration power: 0 W

Refrigerant weight: 140 g

Energy Class (EU Reg. 2015/1094): D

Climate class (EU Reg. 2015/1094): Normal duty (cl.4)

Energy Efficiency Index-EEI (EU Reg. 2015/1094): 71.97

Documents

Product Features

Main Features

Anti-tilt runners accept GN 1/1 containers.

Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.

Digital control panel.

Forced air circulation for rapid cooling and an even temperature distribution.

Refrigerated compartment designed to accept GN 1/1 containers.

Self closing stainless steel doors (< 90°).

Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Adjustable temperature range from -15°C to -22°C.

0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.

Frontal and easy access to all components in the cooling unit.

Certified safety CE requirements.

Small footprint to fit even in limited environments.

Tropicalized unit.

Sustainability

Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).

Hot gas automatic evaporation of defrost water.

User Interface & Data Management

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.

Easy serviceability thanks to the intuitive control panel with access via app.

Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Connect the product (with accessory) to the OneConnected Platform via Wi Fi or ethernet connection for a seamless remote experience. Real-time monitoring and analytics, alarm management, HACCP data management, APIs, and advanced features keep your fridge fully under control.

Construction

Access to all components from the front.

Built-in compressor to suit operating conditions.

Developed and produced in ISO 9001 and ISO 14001 certified factory.

Fault code display.

Interior base with rounded corners, pressed from a single sheet.

Internal and external doors, front, back and side panels in AISI 304 Stainless steel.

Pre-arranged for drain-pipe.

Built-in refrigeration unit.

Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.

Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.

Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.

Extractable cooling unit to facilitate maintenance.

IP21 protection index.

Included Accessories


Quantity

Code

Description

Quantity: 1

Code: 881109

Kit 1/1 grey rilsan grid and 2 side runners for refrigerated counters

Detergents and Chemicals (not included)


Code

Description

Code: 0S2881

Code: 0S2883

Code: 0S2884

Code: 0S3257
