Digital Undercounter ecostore HP Concept Freezer Counter, 2 Doors with cooling unit right (R290) (COD 710359)
Where to buy
Digital Undercounterecostore HP Concept Freezer Counter, 2 Doors with cooling unit right (R290)
Digital Undercounterecostore HP Concept Freezer Counter, 2 Doors with cooling unit right (R290)
ecostore HP Concept Freezers Counters - 2 comp. - with top

Digital Undercounter
ecostore HP Concept Freezer Counter, 2 Doors with cooling unit right (R290)

COD 710359

2-door Freezer Counter, -22-15°C, AISI 304 (R290), with right cooling unit

Where to buy
Register your product

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.49 kW

    Defrost Power: 0.57 kW

    Plug type: CE-SCHUKO

  • Current consumption: 3.3 Amps

    Energy Class (EU Reg. 2015/1094): C

    Yearly and daily energy consumption (EU Reg. 2015/1094): 1564kWh/year - 4kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 45,78

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 569 W

    Refrigerant weight: 145 g

  • Gross capacity: 290 lt

    Net Volume: 177.4 lt

    Door hinges: 1 Left+1 Right

    External dimensions, Width: 1345 mm

    External dimensions, Depth: 700 mm

    External dimensions, Height: 900 mm

    Internal Dimensions, Width: 798 mm

    Internal Dimensions, Depth: 560 mm

    Internal Dimensions, Height: 550 mm

    Net weight: 115 kg

    Shipping volume: 1.13 m³

    Depth with doors open: 1110 mm

    Height adjustment: 0/0 mm

  • Control type: Digital

    Compressor power:

    Refrigeration power at evaporation temperature: -30 °C

    Min/Max internal humidity:

    Operating temperature min.: -15 °C

    Operating temperature max.: -22 °C

    Operating mode: Ventilated

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Product Features

Anti-tilt runners accept GN 1/1 containers.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Combination of doors and drawers to suit any configuration need, with the possibility to change the configuration on site.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Certified safety CE requirements.
Self closing stainless steel doors (< 90°).
External back panel in galvanized steel.
External bottom panel in stainless steel.
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Adjustable temperature range from -15°C to -22°C.
Frontal and easy access to all components in the cooling unit.
Hot gas automatic evaporation of defrost water.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
2 compartments with 2 doors.
Anti-drip profile on stainless steel worktop edge.
Built-in refrigeration unit.
Mounted on Stainless steel legs to give 150 mm clearance for ease of cleaning the floor.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Excellent space optimisation thanks to the compact dimensions.
Extractable cooling unit to facilitate maintenance.
Interior base with rounded corners, pressed from a single sheet.
Fault code display.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
