Main Features
Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Hot gas automatic evaporation of defrost water.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Self closing stainless steel doors (< 90°).
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Frontal and easy access to all components in the cooling unit.
Certified safety CE requirements.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Anti-tilt runners accept GN 1/1 containers.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Tropicalized unit.
Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.
Refrigerated compartment designed to accept GN 1/1 containers.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Digital control panel.
Forced air circulation for rapid cooling and an even temperature distribution.
Sustainability
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Top energy efficiency (class A) and granted uniformity even at extreme working conditions (class 5; 40°C and 40% humidity): unbeatable performance, certified by energy test protocol EN16825:2016.
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Construction
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Excellent space optimisation thanks to the compact dimensions.
External back panel in galvanized steel.
Fault code display.
Extractable cooling unit to facilitate maintenance.
Interior base with rounded corners, pressed from a single sheet.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
3 compartments with 3 doors.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Built-in refrigeration unit.
Pre-arranged for drain-pipe.
Anti-drip profile on stainless steel worktop edge.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
External bottom panel in stainless steel.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Built-in compressor to suit operating conditions.
Constructed from AISI 304 Stainless steel throughout to meet the highest hygiene standards.
Rounded internal corners for ease of cleaning.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Access to all components from the front.
