Main Features
Anti-tilt runners accept GN 1/1 containers.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Digital control panel with temperature display.
Forced air circulation for rapid cooling and an even temperature distribution.
Freezer compartment designed to accept GN1/1 containers.
Adjustable temperature range from -15 °C to -22 °C to suit meat, fish and dairy storage requirements.
Self closing stainless steel doors (< 90°).
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Frontal and easy access to all components in the cooling unit.
Certified safety CE requirements.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Tropicalized unit.
Sustainability
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Hot gas automatic evaporation of defrost water.
User Interface & Data Management
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Construction
Access to all components from the front.
Built-in compressor to suit operating conditions.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Interior base with rounded corners, pressed from a single sheet.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Full stainless steel construction. Internal structure and worktop in AISI 304 Stainless steel.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Rounded internal corners for ease of cleaning.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Pre-arranged for drain-pipe.
Built-in refrigeration unit.
Anti-drip profile on stainless steel worktop edge.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
External bottom panel in stainless steel.
External back panel in galvanized steel.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Excellent space optimisation thanks to the compact dimensions.
Extractable cooling unit to facilitate maintenance.
Internal dimension of the drawers: - models with 2 1/2 drawers: 1st drawer (top drawer) 203x302x521 / 2nd drawer 223x302x521 (HxWxD) - models with 3 1/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd and 3rd drawers 118x302x521 (HxWxD) - models with 1/3+2/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd drawer 333x302x521 (HxWxD)
