Prostore 800 1 Door Digital Refrigerator, 720lt (0/+10 °C) - R290 (COD 691349)
Where to buy
Prostore 8001 Door Digital Refrigerator, 720lt (0/+10 °C) - R290
Prostore Digital 800 liters (R290)

Prostore 800
1 Door Digital Refrigerator, 720lt (0/+10 °C) - R290

COD 691349

1-door prostore Refrigerator 720lt, 0+10°C, AISI 304, R290

Where to buy

Specifications

  • Number and type of grids (included): 5 - 530x700

    Capacity:

    Gross capacity calculated according to EN441 is 645Lt on reference to internal dimentions.

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power, max: 0.17 kW

  • Net Volume: 510 lt

    Door hinges:

    External dimensions, Width: 900 mm

    External dimensions, Depth: 700 mm

    External dimensions, Depth with Doors Open: 1527 mm

    External dimensions, Height: 2040 mm

    Number and type of doors: 1 Full

    Internal Dimensions, Width: 772 mm

    Internal Dimensions, Depth: 582 mm

    Internal Dimensions, Height: 1436 mm

    Height adjustment: 15/40 mm

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Number of positions & pitch: 44; 22 mm

    Gross capacity: 720 lt

    Type of model (EU Regulation. 2015/1094): vertical chilled

  • Control type: Digital

    Refrigeration power at evaporation temperature: -10 °C

    Operating temperature min.: 0 °C

    Operating temperature max.: 10 °C

    Compressor power: 1/4 hp

    Operating mode: Ventilated

    Cooling unit: Built-In

    Defrost type: By Air

  • Noise level: 52 dBA

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 406 W

    Refrigerant weight (unit 1): 115 g

    Energy Class (EU Reg. 2015/1094): B

    Yearly and daily energy consumption (EU Reg. 2015/1094): 506kWh/year - 1.39kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 34.96

Product Features

Main Features

IPX5 frontal water protection.
Large storage area suitable to contain 700x530 mm grids to improve net capacity.
Low noise level.
Optimized airflow within the chamber guarantees uniformity of temperature on all grids.
Complies with main international certification bodies and is CE marked.
Large storage area suitable to contain 700x530 mm grids to improve net capacity.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Optimized airflow within the chamber guarantees uniformity of temperature on all grids.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.
Optimized airflow within the chamber guarantees uniformity of temperature on all grids.
Adjustable temperature range from 0°C to +10°C.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.
Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.
Adjustable temperature range from 0°C to +10°C.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.
High resistance foot pedal included.
Complies with main international certification bodies and is CE marked.
High resistance foot pedal included.
Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.
Adjustable temperature range from 0°C to +10°C.
Self closing and on site reversible left/right doors.
Large storage area suitable to contain 700x530 mm grids to improve net capacity.
Self closing and on site reversible left/right doors.
Prearranged for remote alarm.
IPX5 frontal water protection.
Low noise level.
Prearranged for remote alarm.
ECA listed.
ECA listed.
IPX5 frontal water protection.
This appliance is intended for use in ambient temperatures up to 40°C.
This appliance is intended for use in ambient temperatures up to 40°C.
Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.
Tropicalized unit.
Tropicalized unit.
Tropicalized unit.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Complies with main international certification bodies and is CE marked.
High resistance foot pedal included.
Prearranged for remote alarm.
Self closing and on site reversible left/right doors.
Low noise level.
This appliance is intended for use in ambient temperatures up to 40°C.
ECA listed.

Sustainability

Optical door microswitch to stop the fan once the door is opened, thus minimizing energy waste.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Cleaning-free condenser: the structure of the wire frame condenser prevents dust and grease accumulation thus avoiding periodical cleaning operations and reducing energy consumption.
Frost Watch Control: fully automatic defrost starts only when ice is actually building-up in the evaporator and adapt the defrosting duration to guarantee perfect ice removal while optimizing energy efficiency consumption.
Interior LED light to save energy and for best internal visibility.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Frost Watch Control: fully automatic defrost starts only when ice is actually building-up in the evaporator and adapt the defrosting duration to guarantee perfect ice removal while optimizing energy efficiency consumption.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Insulation thickness: 65 mm of polyurethane injected with ecological foaming gas cyclopentane to ensure effective insulation with minimum energy consumption (thermal conductivity: 0,020 W/m*K).
Insulation thickness: 65 mm of polyurethane injected with ecological foaming gas cyclopentane to ensure effective insulation with minimum energy consumption (thermal conductivity: 0,020 W/m*K).
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Cleaning-free condenser: the structure of the wire frame condenser prevents dust and grease accumulation thus avoiding periodical cleaning operations and reducing energy consumption.
Optical door microswitch to stop the fan once the door is opened, thus minimizing energy waste.
Interior LED light to save energy and for best internal visibility.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.

User Interface & Data Management

Large digital white-digit display with humidity selection button (3 preset level), cabinet temperature display and setting and turbo frost cycle (to rapidly cool warm loads).
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Large digital white-digit display with cabinet temperature display and setting, and possibility to select the desired levels of humidity. Bluetooth technology included allows to keep HACCP historical data and download them through the app.
Electrolux Professional Fridge Control APP makes the life easier for our customers: ​- Monitor safety of preservation process thanks to HACCP data & alarms for precise control​​- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address​- Quick operations:​ set the cabinet temperature/humidity/turbocooling​ and set date/hour
Large digital white-digit display with cabinet temperature display and setting, and possibility to select the desired levels of humidity. Bluetooth technology included allows to keep HACCP historical data and download them through the app.
Electrolux Professional Fridge Control APP makes the life easier for our customers: ​- Monitor safety of preservation process thanks to HACCP data & alarms for precise control​​- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address​- Quick operations:​ set the cabinet temperature/humidity/turbocooling​ and set date/hour
Large digital white-digit display with humidity selection button (3 preset level), cabinet temperature display and setting and turbo frost cycle (to rapidly cool warm loads).

Construction

Stainless steel AISI 304 external panels (galvanized external back).
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Stainless steel AISI 304 external panels (galvanized external back).
Inner cell with rounded corners, bottom pressed in only one piece.
Lockable door.
Stainless steel runners and supports easily disassembled.
Lockable door.
Inner cell with rounded corners, bottom pressed in only one piece.
Internal components removable without the use of tools to facilitate cleaning operations.
Inner cell with rounded corners, bottom pressed in only one piece.
Stainless steel runners and supports easily disassembled.
Internal components removable without the use of tools to facilitate cleaning operations.
Pressed stainless steel door handle without joints gathering dust and dirt.
Easy access to the main components for maintenance.
Pressed stainless steel door handle without joints gathering dust and dirt.
Stainless steel runners and supports easily disassembled.
Easy access to the main components for maintenance.
Easy access to the main components for maintenance.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Pressed stainless steel door handle without joints gathering dust and dirt.
Stainless steel AISI 304 external panels (galvanized external back).
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Internal components removable without the use of tools to facilitate cleaning operations.
Lockable door.

Included Accessories

Quantity
Code
Description
Quantity: 1
Code: 880324
Pedal opening for cabinets
Quantity: 5
Code: 880335
Pair of runners for 470 and 720lt prostore cabinets
Quantity: 5
Code: 880343
Plastic-coated grid 700x530mm for Prostore 720l

Detergents and Chemicals (not included)

Code
Description
Code: 0S2881
Code: 0S2883
Code: 0S2884
Code: 0S3257
