Prostore 500 2½ Door Digital Freezer, 470lt (-15/-22 °C) - R290 (COD 691354)
Where to buy
Prostore 5002½ Door Digital Freezer, 470lt (-15/-22 °C) - R290
Prostore 5002½ Door Digital Freezer, 470lt (-15/-22 °C) - R290
Prostore Digital 500 liters (R290)

Prostore 500
2½ Door Digital Freezer, 470lt (-15/-22 °C) - R290

COD 691354

2x½-door prostore Freezer 470lt, -22-15°C, AISI 304, R290

Where to buy

Specifications

  • Number and type of grids (included): 5 - 520x442

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power, max: 0.41 kW

  • Net Volume: 317 lt

    Door hinges:

    External dimensions, Width: 600 mm

    External dimensions, Depth: 700 mm

    External dimensions, Depth with Doors Open: 1226 mm

    External dimensions, Height: 2040 mm

    Number and type of doors: 2x1/2 Full

    Internal Dimensions, Width: 472 mm

    Internal Dimensions, Depth: 582 mm

    Internal Dimensions, Height: 1474 mm

    Height adjustment: 15/40 mm

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Number of positions & pitch: 44; 22 mm

    Gross capacity: 470 lt

    Type of model (EU Regulation. 2015/1094): vertical frozen

  • Control type: Digital

    Refrigeration power at evaporation temperature: -30 °C

    Operating temperature min.: -22 °C

    Operating temperature max.: -15 °C

    Compressor power: 3/4 hp

    Operating mode: Ventilated

    Cooling unit: Built-In

    Defrost type: Electric

  • Noise level: 55 dBA

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 569 W

    Refrigerant weight (unit 1): 145 g

    Energy Class (EU Reg. 2015/1094): D

    Yearly and daily energy consumption (EU Reg. 2015/1094): 2100kWh/year - 6kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 69.21

Product Features

Main Features

IPX5 frontal water protection.
Large storage area suitable to contain 520x442 mm grids or shelves to improve net capacity.
Large storage area suitable to contain 520x442 mm grids or shelves to improve net capacity.
Optimized airflow within the chamber guarantees uniformity of temperature on all grids.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Optimized airflow within the chamber guarantees uniformity of temperature on all grids.
Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.
Adjustable temperature range from -15°C to -22°C.
Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.
Complies with main international certification bodies and is CE marked.
Adjustable temperature range from -15°C to -22°C.
Self closing and on site reversible left/right doors.
Prearranged for remote alarm.
Low noise level.
IPX5 frontal water protection.
This appliance is intended for use in ambient temperatures up to 40°C.
Tropicalized unit.
Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.
Tropicalized unit.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Complies with main international certification bodies and is CE marked.
Prearranged for remote alarm.
Low noise level.
Self closing and on site reversible left/right doors.
This appliance is intended for use in ambient temperatures up to 40°C.

Sustainability

Frost Watch Control: fully automatic defrost starts only when ice is actually building-up in the evaporator and adapt the defrosting duration to guarantee perfect ice removal while optimizing energy efficiency consumption.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Insulation thickness: 65 mm of polyurethane injected with ecological foaming gas cyclopentane to ensure effective insulation with minimum energy consumption (thermal conductivity: 0,020 W/m*K).
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Optical door microswitch to stop the fan once the door is opened, thus minimizing energy waste.
Interior LED light to save energy and for best internal visibility.

User Interface & Data Management

Large digital white-digit display with cabinet temperature display and setting and turbo frost cycle (to rapidly cool warm loads).
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Electrolux Professional Fridge Control APP makes the life easier for our customers: ​- Monitor safety of preservation process thanks to HACCP data & alarms for precise control​​- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address​- Quick operations:​ set the cabinet temperature/turbocooling​ and set date/hour
Large digital white-digit display with cabinet temperature display and setting. Bluetooth technology included allows to keep HACCP historical data and download them through the app.

Construction

Stainless steel AISI 304 external panels (galvanized external back).
Lockable door.
Stainless steel AISI 304 external panels (galvanized external back).
Inner cell with rounded corners, bottom pressed in only one piece.
Inner cell with rounded corners, bottom pressed in only one piece.
Stainless steel runners and supports easily disassembled.
Stainless steel runners and supports easily disassembled.
Internal components removable without the use of tools to facilitate cleaning operations.
Pressed stainless steel door handle without joints gathering dust and dirt.
Internal components removable without the use of tools to facilitate cleaning operations.
Pressed stainless steel door handle without joints gathering dust and dirt.
Easy access to the main components for maintenance.
Easy access to the main components for maintenance.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Automatic heated door frame.
Lockable door.
Automatic heated door frame.

Included Accessories

Quantity
Code
Description
Quantity: 4
Code: 880335
Pair of runners for 470 and 720lt prostore cabinets
Quantity: 4
Code: 880342
Rilsan-coated grid 520x442mm for Prostore 470l

Detergents and Chemicals (not included)

Code
Description
Code: 0S2881
Code: 0S2883
Code: 0S2884
Code: 0S3257
