Prostore 800 2½ Door Digital Refrigerator, 720lt (0/+10 °C) - R290 (COD 691351)

Compare Where to buy

Prostore Digital 800 liters (R290)

Prostore 800
2½ Door Digital Refrigerator, 720lt (0/+10 °C) - R290

COD 691351

2-½ door prostore Refrigerator 720lt, 0+10°C, AISI 304, R290

Compare

Where to buy

Specifications

Capacity

Number and type of grids (included): 5 - 530x700
ISO Certificates

ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001
Electric

Supply voltage: 220-240 V/1 ph/50 Hz

Electrical power, max: 0.17 kW
Key Information

Net Volume: 510 lt

Door hinges:

External dimensions, Width: 900 mm

External dimensions, Depth: 700 mm

External dimensions, Depth with Doors Open: 1527 mm

External dimensions, Height: 2040 mm

Number and type of doors: 2x1/2 Full

Internal Dimensions, Width: 772 mm

Internal Dimensions, Depth: 582 mm

Internal Dimensions, Height: 1436 mm

Height adjustment: 15/40 mm

Type of external material: 304 AISI

Type of internal material: 304 AISI

Number of positions & pitch: 44; 22 mm

Gross capacity: 720 lt

Type of model (EU Regulation. 2015/1094): vertical chilled
Refrigeration Data

Control type: Digital

Refrigeration power at evaporation temperature: -10 °C

Operating temperature min.: 0 °C

Operating temperature max.: 10 °C

Compressor power: 1/4 hp

Operating mode: Ventilated

Cooling unit: Built-In

Defrost type: By Air
Sustainability

Refrigerant type: R290

GWP Index: 3

Refrigeration power: 406 W

Refrigerant weight (unit 1): 115 g

Energy Class (EU Reg. 2015/1094): B

Yearly and daily energy consumption (EU Reg. 2015/1094): 506kWh/year - 1kWh/24h

Climate class (EU Reg. 2015/1094): Heavy Duty (5)

Energy Efficiency Index-EEI (EU Reg. 2015/1094): 34.96

Documents

Product Features

Main Features

IPX5 frontal water protection.

Prearranged for remote alarm.

Large storage area suitable to contain 700x530 mm grids to improve net capacity.

IPX5 frontal water protection.

Optimized airflow within the chamber guarantees uniformity of temperature on all grids.

Large storage area suitable to contain 700x530 mm grids to improve net capacity.

Optimized airflow within the chamber guarantees uniformity of temperature on all grids.

Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.

Adjustable temperature range from 0°C to +10°C.

Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.

Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.

Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Adjustable temperature range from 0°C to +10°C.

Complies with main international certification bodies and is CE marked.

Self closing and on site reversible left/right doors.

This appliance is intended for use in ambient temperatures up to 40°C.

Tropicalized unit.

Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.

Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Complies with main international certification bodies and is CE marked.

Prearranged for remote alarm.

Self closing and on site reversible left/right doors.

Low noise level.

This appliance is intended for use in ambient temperatures up to 40°C.

Sustainability

Frost Watch Control: fully automatic defrost starts only when ice is actually building-up in the evaporator and adapt the defrosting duration to guarantee perfect ice removal while optimizing energy efficiency consumption.

CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.

Insulation thickness: 65 mm of polyurethane injected with ecological foaming gas cyclopentane to ensure effective insulation with minimum energy consumption (thermal conductivity: 0,020 W/m*K).

Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

Cleaning-free condenser: the structure of the wire frame condenser prevents dust and grease accumulation thus avoiding periodical cleaning operations and reducing energy consumption.

Optical door microswitch to stop the fan once the door is opened, thus minimizing energy waste.

Interior LED light to save energy and for best internal visibility.

Automatic evaporation of the defrosting water by hot gas on the top for energy saving.

User Interface & Data Management

Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

Large digital white-digit display with humidity selection button (3 preset level), cabinet temperature display and setting and turbo frost cycle (to rapidly cool warm loads).

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.

Electrolux Professional Fridge Control APP makes the life easier for our customers: - Monitor safety of preservation process thanks to HACCP data & alarms for precise control- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address- Quick operations: set the cabinet temperature/humidity/turbocooling and set date/hour

Large digital white-digit display with cabinet temperature display and setting, and possibility to select the desired levels of humidity. Bluetooth technology included allows to keep HACCP historical data and download them through the app.

Construction

Stainless steel AISI 304 external panels (galvanized external back).

Developed and produced in ISO 9001 and ISO 14001 certified factory.

Lockable door.

Inner cell with rounded corners, bottom pressed in only one piece.

Stainless steel runners and supports easily disassembled.

Stainless steel AISI 304 external panels (galvanized external back).

Internal components removable without the use of tools to facilitate cleaning operations.

Inner cell with rounded corners, bottom pressed in only one piece.

Pressed stainless steel door handle without joints gathering dust and dirt.

Stainless steel runners and supports easily disassembled.

Easy access to the main components for maintenance.

Internal components removable without the use of tools to facilitate cleaning operations.

Developed and produced in ISO 9001 and ISO 14001 certified factory.

Pressed stainless steel door handle without joints gathering dust and dirt.

Easy access to the main components for maintenance.

Lockable door.

Included Accessories


Quantity

Code

Description

Quantity: 4

Code: 880335

Pair of runners for 470 and 720lt prostore cabinets

Quantity: 4

Code: 880343

Plastic-coated grid 700x530mm for Prostore 720l

Detergents and Chemicals (not included)


Code

Description

Code: 0S2881

Code: 0S2883

Code: 0S2884

Code: 0S3257
