ecostore Premium HPe 1 Door Freezer 670lt, pressed guides, -22-15, Class B (COD 725664)
Where to buy
ecostore Premium HPe 670 liters Digital Freezers (R290)

ecostore Premium HPe
1 Door Freezer 670lt, pressed guides, -22-15, Class B

COD 725664

1-door Freezer 670lt, -22-15°C (R290), pressed guides, digital, AISI 304, Class B

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.3 kW

  • Number and type of grids (included): 4 (GN 2/1)

  • Net Volume: 496 lt

    External dimensions, Width: 740 mm

    External dimensions, Depth: 885 mm

    External dimensions, Depth with Doors Open: 1507 mm

    External dimensions, Height: 2080 mm

    Number and type of doors: 1 Full

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Internal panels material: 304 AISI

    Number of positions & pitch: 24; 55 mm

    Gross capacity: 670 liter

    Type of model: vertical freezer

  • Control type: Digital

    Refrigeration power at evaporation temperature: -30 °C

    Operating temperature min.: -15 °C

    Operating temperature max.: -22 °C

    Compressor power: 1 hp

    Operating mode: Ventilated

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 569 W

    Refrigerant weight: 90 g

    Energy Class (EU Reg. 2015/1094): B

    Yearly and daily energy consumption (EU Reg. 2015/1094): 1325kWh/year - 3.63kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 33.83

Product Features

Main Features

Combining outstanding energy efficiency with reliable performance, the HPe range stands out thanks to its innovative pressed guides design and refined ergonomics.
Combining outstanding energy efficiency with reliable performance, the HPe range stands out thanks to its innovative pressed guides design and refined ergonomics.
Multi-directional Optiflow system ensures consistent cooling distribution throughout the cabinet, even at full capacity; it is enabled by the vertical optimized spacing between guides, which facilitates unobstructed air circulation (Patent Pending - EP25203398.0).
Multi-directional Optiflow system ensures consistent cooling distribution throughout the cabinet, even at full capacity; it is enabled by the vertical optimized spacing between guides, which facilitates unobstructed air circulation (Patent Pending - EP25203398.0).
Cabinet fitted with up to 90 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
Cabinet fitted with up to 90 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
Performance guaranteed at ambient temperatures of +40°C (Climatic class 5).
Performance guaranteed at ambient temperatures of +40°C (Climatic class 5).
Large storage area suitable to contain 2/1 GN grids or shelves on on anti-tilt pressed guides.
Large storage area suitable to contain 2/1 GN grids or shelves on on anti-tilt pressed guides.
Rilsan coated grids for improved protection.
Tropicalized unit.
Tropicalized unit.

Sustainability

Frost Watch Control: fully automatic defrost starts only when ice is actually building-up in the evaporator and adapt the defrosting duration to guarantee perfect ice removal while optimizing energy efficiency consumption.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Interior LED light to save energy and for best internal visibility.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
The one-piece pressed guides, together with rounded internal corners, ensure fast and hygienic cleaning to the highest standards.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated.
Cleaning-free condenser: the structure of the wire frame condenser prevents dust and grease accumulation thus avoiding periodical cleaning operations and reducing energy consumption.
Constructed from the highest quality AISI 304 Stainless steel.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Interior LED light to save energy and for best internal visibility.
Electrolux Professional Fridge Control APP makes the life easier for our customers: ​- Monitor safety of preservation process thanks to HACCP data & alarms for precise control​​- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address​- Quick operations:​ set the cabinet temperature/turbocooling​ and set date/hour
Easy access to the main components for maintenance.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Large digital white-digit display with cabinet temperature display and setting. Bluetooth technology included allows to keep HACCP historical data and download them through the app.
Lockable door.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Frost Watch Control: fully automatic defrost starts only when ice is actually building-up in the evaporator and adapt the defrosting duration to guarantee perfect ice removal while optimizing energy efficiency consumption.
Cabinet certified as Class B in heavy duty working conditions (40°C-40% humidity) based on European Ecodesign directive.
Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Cabinet certified as Class B in heavy duty working conditions (40°C-40% humidity) based on European Ecodesign directive.

User Interface & Data Management

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated.
The one-piece pressed guides, together with rounded internal corners, ensure fast and hygienic cleaning to the highest standards.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
Interior LED light to save energy and for best internal visibility.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Easy access to the main components for maintenance.
Electrolux Professional Fridge Control APP makes the life easier for our customers: ​- Monitor safety of preservation process thanks to HACCP data & alarms for precise control​​- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address​- Quick operations:​ set the cabinet temperature/turbocooling​ and set date/hour
Electrolux Professional Fridge Control APP makes the life easier for our customers: ​- Monitor safety of preservation process thanks to HACCP data & alarms for precise control​​- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address​- Quick operations:​ set the cabinet temperature/turbocooling​ and set date/hour
Large digital white-digit display with cabinet temperature display and setting. Bluetooth technology included allows to keep HACCP historical data and download them through the app.
Lockable door.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Large digital white-digit display with cabinet temperature display and setting. Bluetooth technology included allows to keep HACCP historical data and download them through the app.

Construction

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated.
The one-piece pressed guides, together with rounded internal corners, ensure fast and hygienic cleaning to the highest standards.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
The one-piece pressed guides, together with rounded internal corners, ensure fast and hygienic cleaning to the highest standards.
Constructed from the highest quality AISI 304 Stainless steel.
Cleaning-free condenser: the structure of the wire frame condenser prevents dust and grease accumulation thus avoiding periodical cleaning operations and reducing energy consumption.
Constructed from the highest quality AISI 304 Stainless steel.
Interior LED light to save energy and for best internal visibility.
Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
Electrolux Professional Fridge Control APP makes the life easier for our customers: ​- Monitor safety of preservation process thanks to HACCP data & alarms for precise control​​- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address​- Quick operations:​ set the cabinet temperature/turbocooling​ and set date/hour
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Easy access to the main components for maintenance.
Easy access to the main components for maintenance.
Large digital white-digit display with cabinet temperature display and setting. Bluetooth technology included allows to keep HACCP historical data and download them through the app.
Lockable door.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Lockable door.

Included Accessories

Quantity
Code
Description
Quantity: 4
Code: 881004
2/1GN grey rilsan grid
