ecostore HPe 1 Door Refrigerator 670lt, pressed guides and light, -2 +10, Class A (COD 725669)
Where to buy
ecostore HPe 670 liters Digital Refrigerators (R290)

ecostore HPe
1 Door Refrigerator 670lt, pressed guides and light, -2 +10, Class A

COD 725669

1-door Refrigerator 670lt, -2+10°C, pressed guides, digital, AISI 304, with internal light, R290, Class A

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.19 kW

  • Number and type of grids (included): 3 (GN 2/1)

  • Net Volume: 496 lt

    External dimensions, Width: 740 mm

    External dimensions, Depth: 860 mm

    External dimensions, Depth with Doors Open: 1480 mm

    External dimensions, Height: 2080 mm

    Number and type of doors: 1 Full

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Internal panels material: 304 AISI

    Number of positions & pitch: 24; 55 mm

    Gross capacity: 670 liter

    Type of model: Vertical chilled

  • Control type: Digital

    Refrigeration power at evaporation temperature: -10 °C

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Compressor power: 1/5 hp

    Operating mode: Ventilated

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 278 W

    Refrigerant weight: 110 g

    Energy Class (EU Reg. 2015/1094): A

    Yearly and daily energy consumption (EU Reg. 2015/1094): 340kWh/year - 0.93kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 23.89

Product Features

Main Features

Automatic defrost.
Combining outstanding energy efficiency with reliable performance, the HPe range stands out thanks to its innovative pressed guides design and refined ergonomics.
Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.
Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Multi-directional Optiflow system ensures consistent cooling distribution throughout the cabinet, even at full capacity; it is enabled by the vertical optimized spacing between guides, which facilitates unobstructed air circulation (Patent Pending - EP25203398.0).
Cabinet fitted with up to 90 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
Cabinet fitted with up to 90 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
Tropicalized unit.
Multi-directional Optiflow system ensures consistent cooling distribution throughout the cabinet, even at full capacity; it is enabled by the vertical optimized spacing between guides, which facilitates unobstructed air circulation (Patent Pending - EP25203398.0).
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Combining outstanding energy efficiency with reliable performance, the HPe range stands out thanks to its innovative pressed guides design and refined ergonomics.
Tropicalized unit.
Automatic defrost.

Sustainability

Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Lockable door.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Mounted on adjustable Stainless steel feet, with castors as an option.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Easy serviceability thanks to the intuitive control panel with access via app.
Easy access to the main components for maintenance.
Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

User Interface & Data Management

Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Lockable door.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
Easy access to the main components for maintenance.
Easy serviceability thanks to the intuitive control panel with access via app.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Easy serviceability thanks to the intuitive control panel with access via app.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.

Construction

Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Lockable door.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
The one-piece pressed guides, together with rounded internal corners, ensure fast and hygienic cleaning to the highest standards.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Mounted on adjustable Stainless steel feet, with castors as an option.
Easy access to the main components for maintenance.
Easy serviceability thanks to the intuitive control panel with access via app.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Easy access to the main components for maintenance.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Doors are self-closing and can be fully opened up to 180°.
The one-piece pressed guides, together with rounded internal corners, ensure fast and hygienic cleaning to the highest standards.
Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Doors are self-closing and can be fully opened up to 180°.
Lockable door.
Mounted on adjustable Stainless steel feet, with castors as an option.

Included Accessories

Quantity
Code
Description
Quantity: 3
Code: 881004
2/1GN grey rilsan grid
