ecostore 1 Door Digital Refrigerator, 670lt (-2/+10), AISI 304 Marine (R290) (COD 725233)
Where to buy
ecostore1 Door Digital Refrigerator, 670lt (-2/+10), AISI 304 Marine (R290)
ecostore 670 - 1430 liters Digital Refrigerators (R290)

ecostore
1 Door Digital Refrigerator, 670lt (-2/+10), AISI 304 Marine (R290)

COD 725233

1-door Refrigerator 670lt, -2+10°C, digital, AISI 304, R290, 60Hz (Marine)

Where to buy
Register your product

Specifications

  • Number and type of grids (included): 3 - GN 2/1

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Supply voltage: 208-230 V/1 ph/60 Hz

    Electrical power, max: 0.22 kW

  • Net Volume: 503 lt

    Door hinges:

    External dimensions, Width: 710 mm

    External dimensions, Depth: 835 mm

    External dimensions, Depth with Doors Open: 1480 mm

    External dimensions, Height: 2050 mm

    Number and type of doors: 1 Full

    Type of external material: 304 AISI

    Type of internal material: 304 AISI

    Internal panels material: 304 AISI

    Number of positions & pitch: 44; 30 mm

    Gross capacity: 670 lt

    Type of model (EU Regulation. 2015/1094): vertical chilled

  • Control type: Digital

    Refrigeration power at evaporation temperature: -10 °C

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Compressor power: 1/5 hp

    Operating mode: Ventilated

  • Refrigerant type: R290

    Refrigeration power: 414 W

    Refrigerant weight (unit 1): 75 g

    Energy Class (EU Reg. 2015/1094): C

    Yearly and daily energy consumption (EU Reg. 2015/1094): 712kWh/year - 1.95kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 49.58

Product Features

Main Features

Cabinet fitted with up to 75 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Internal structure with numerous charging positions available to host grids, ensuring higher net capacity and a greater storage space.
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
Optimized back to front forced air flow provide even temperature distribution and fast cooling in any conditions.
Tropicalized unit.
Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.
Automatic defrost.
Equipped with single phase electrical cable and Schuko plug for easy and fast installation.
Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.
Right hinged full door.

Sustainability

Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Cleaning-free condenser: the structure of the wire frame condenser prevents dust and grease accumulation thus avoiding periodical cleaning operations and reducing energy consumption.

User Interface & Data Management

Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Easy serviceability thanks to the intuitive control panel with access via app.
Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.

Construction

Easy access to the main components for maintenance.
Stainless steel runners and supports easily disassembled.
Constructed from the highest quality AISI 304 Stainless steel.
Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Doors are self-closing and can be fully opened up to 180°.
Lockable door.
The rounded internal corners, the easily removable runners and grids allow for ease of cleaning and high hygiene standards.
Mounted on adjustable Stainless steel feet, with castors as an option.

Included Accessories

Quantity
Code
Description
Quantity: 3
Code: 880242
2 stainless steel runners for refrigerated cabinets - (Marine)
Quantity: 3
Code: 881004
2/1GN grey rilsan grid
