Digital Undercounter ecostore HP Premium Refrigerated Counter - 290lt, 2-Door, Upstand (COD 710002)
Where to buy
Digital Undercounterecostore HP Premium Refrigerated Counter - 290lt, 2-Door, Upstand
ecostore HP Premium Ref. Counters - 2 comp. - with top and upstand

Digital Undercounter
ecostore HP Premium Refrigerated Counter - 290lt, 2-Door, Upstand

COD 710002

2-door Refrigerated Counter 290lt, -2+10°C, AISI 304, with splashback

Fast range available in stock. (click to discover more)

Where to buy
Product registration

Specifications

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power, max: 0.25 kW

    Defrost Power: 0.22 kW

    Plug type: CE-SCHUKO

  • Net Volume: 198 lt

    Door hinges:

    External dimensions, Width: 1345 mm

    External dimensions, Depth: 700 mm

    External dimensions, Height: 1000 mm

    Internal Dimensions, Width: 798 mm

    Internal Dimensions, Depth: 560 mm

    Internal Dimensions, Height: 550 mm

    Net weight: 106 kg

    Shipping volume: 1.21 m³

    Depth with doors open: 1110 mm

    Height adjustment: -5/50 mm

    Gross capacity: 290 lt

  • Control type: Digital

    Refrigeration power at evaporation temperature: -10 °C

    Min/Max internal humidity: 40/85

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Compressor power: 1/4 hp

    Operating mode: Ventilated

    Insulation: 90 mm (Cyclopentane)

  • Current consumption: 1.8 Amps

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 320 W

    Refrigerant weight (unit 1): 70 g

    Energy Class (EU Reg. 2015/1094): A

    Yearly and daily energy consumption (EU Reg. 2015/1094): 456kWh/year - 1.25kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 19,86

Product Features

Main Features

Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.
Raised rear upstand permits unit to be connected up against the wall for better hygiene.
Equipped with Optiflow forced air circulation system for rapid cooling and temperature distribution within the cell.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Fully removable cooling unit to facilitate maintenance.
Frontal and easy access to all components in the cooling unit.
Anti-tilt runners accept GN 1/1 containers.
Self closing stainless steel doors (< 90°).
Certified safety CE requirements.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Tropicalized unit.

Construction

2 compartments with 2 doors.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Anti-drip profile on stainless steel worktop edge.
Interior base with rounded corners, pressed from a single sheet.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
External bottom panel in stainless steel.
External back panel in galvanized steel.
Built-in refrigeration unit.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.

Included Accessories

Quantity
Code
Description
Quantity: 2
Code: 881109
Kit 1/1 grey rilsan grid and 2 side runners for refrigerated counters
