Main Features
Anti-tilt runners accept GN 1/1 containers.
Small footprint to fit even in limited environments.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Certified safety CE requirements.
Frontal and easy access to all components in the cooling unit.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Adjustable temperature range from -15°C to -22°C.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Self closing stainless steel doors (< 90°).
Digital control panel.
Self closing stainless steel doors (< 90°).
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Frontal and easy access to all components in the cooling unit.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Digital control panel with temperature display.
Tropicalized unit.
Digital control panel with temperature display.
Freezer compartment designed to accept GN1/1 containers.
Sustainability
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Hot gas automatic evaporation of defrost water.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
User Interface & Data Management
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Construction
Pre-arranged for drain-pipe.
External bottom panel in stainless steel.
Built-in refrigeration unit.
Anti-drip profile on stainless steel worktop edge.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Interior base with rounded corners, pressed from a single sheet.
3 compartments with 3 doors.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Fault code display.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Excellent space optimisation thanks to the compact dimensions.
Extractable cooling unit to facilitate maintenance.
IP21 protection index.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Interior base with rounded corners, pressed from a single sheet.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Pre-arranged for drain-pipe.
Anti-drip profile on stainless steel worktop edge.
Extractable cooling unit to facilitate maintenance.
Built-in compressor to suit operating conditions.
Built-in compressor to suit operating conditions.
Access to all components from the front.
