Main Features
Refrigerated compartment designed to accept GN 1/1 containers.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Self closing stainless steel doors (< 90°).
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Digital control panel.
Frontal and easy access to all components in the cooling unit.
Adjustable temperature range from -15°C to -22°C.
Small footprint to fit even in limited environments.
Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
Forced air circulation for rapid cooling and an even temperature distribution.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Certified safety CE requirements.
Anti-tilt runners accept GN 1/1 containers.
Anti-tilt runners accept GN 1/1 containers.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Digital control panel.
Forced air circulation for rapid cooling and an even temperature distribution.
Refrigerated compartment designed to accept GN 1/1 containers.
Self closing stainless steel doors (< 90°).
Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Frontal and easy access to all components in the cooling unit.
Certified safety CE requirements.
Adjustable temperature range from -15°C to -22°C.
Tropicalized unit.
Tropicalized unit.
Sustainability
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Hot gas automatic evaporation of defrost water.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
User Interface & Data Management
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Construction
Extractable cooling unit to facilitate maintenance.
Built-in compressor to suit operating conditions.
Interior base with rounded corners, pressed from a single sheet.
Internal and external doors, front, back and side panels in AISI 304 Stainless steel.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Rounded internal corners for ease of cleaning.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Built-in refrigeration unit.
Pre-arranged for drain-pipe.
Access to all components from the front.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
IP21 protection index.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Access to all components from the front.
Built-in compressor to suit operating conditions.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Interior base with rounded corners, pressed from a single sheet.
Internal and external doors, front, back and side panels in AISI 304 Stainless steel.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Rounded internal corners for ease of cleaning.
Pre-arranged for drain-pipe.
Built-in refrigeration unit.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Extractable cooling unit to facilitate maintenance.
IP21 protection index.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
