Digital Undercounter ecostore HP Concept Refrigerated Counter - 4 Door (R290) (COD 710475)
Where to buy
Digital Undercounterecostore HP Concept Refrigerated Counter - 4 Door (R290)
ecostore HP Concept Refrigerated Counters - 4 comp. - No top

Digital Undercounter
ecostore HP Concept Refrigerated Counter - 4 Door (R290)

COD 710475

4-door Refrigerated Counter, -2+10°C, AISI 304 (R290), without work top

Where to buy
Product registration

Specifications

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power, max: 0.27 kW

    Defrost Power: 0.2 kW

    Plug type: CE-SCHUKO

  • Net Volume: 361.6 lt

    External dimensions, Width: 2149 mm

    External dimensions, Depth: 700 mm

    External dimensions, Height: 850 mm

    Internal Dimensions, Width: 1706 mm

    Internal Dimensions, Depth: 560 mm

    Internal Dimensions, Height: 550 mm

    Net weight: 118 kg

    Shipping volume: 1.71 m³

    Depth with doors open: 1110 mm

    Height adjustment: -5/50 mm

    Gross capacity: 590 lt

  • Control type: Digital

    Refrigeration power at evaporation temperature: -10 °C

    Min/Max internal humidity: 40/85

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Compressor power: 0.25 hp

    Operating mode: Ventilated

    Insulation: 90 mm (Cyclopentane)

  • Current consumption: 2 Amps

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 358 W

    Refrigerant weight (unit 1): 65 g

    Energy Class (EU Reg. 2015/1094): B

    Yearly and daily energy consumption (EU Reg. 2015/1094): 916kWh/year - 2.51kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 33,75

Product Features

Main Features

Anti-tilt runners accept GN 1/1 containers.
Self closing stainless steel doors (< 90°).
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Frontal and easy access to all components in the cooling unit.
Certified safety CE requirements.
Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.
Refrigerated compartment designed to accept GN 1/1 containers.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Digital control panel.
Forced air circulation for rapid cooling and an even temperature distribution.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Tropicalized unit.

Construction

Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Interior base with rounded corners, pressed from a single sheet.
Pre-arranged for drain-pipe.
Built-in refrigeration unit.
4 compartments with 4 doors.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
External bottom panel in stainless steel.
External back panel in galvanized steel.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Built-in compressor to suit operating conditions.
Constructed from AISI 304 Stainless steel throughout to meet the highest hygiene standards.
Rounded internal corners for ease of cleaning.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Access to all components from the front.
Excellent space optimisation thanks to the compact dimensions.
Extractable cooling unit to facilitate maintenance.

Included Accessories

Quantity
Code
Description
Quantity: 4
Code: 881109
Kit 1/1 grey rilsan grid and 2 side runners for refrigerated counters

Detergents and Chemicals (not included)

Code
Description
Code: 0S2881
Shop now
Code: 0S2883
Shop now
Code: 0S2884
Shop now
Code: 0S3257
Shop now
