Digital Undercounter ecostore HP Concept Refrigerated Counter with Splashback - 3 Door (R290) (COD 714659)
Where to buy
Digital Undercounterecostore HP Concept Refrigerated Counter with Splashback - 3 Door (R290)
ecostore HP Concept Ref. Counters - 3 comp. - with top and upstand

Digital Undercounter
ecostore HP Concept Refrigerated Counter with Splashback - 3 Door (R290)

COD 714659

3-door Refrigerated Counter, -2+10°C, AISI 304 (R290), with splashback

Where to buy
Product registration

Specifications

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power, max: 0.22 kW

    Defrost Power: 0.27 kW

    Plug type: CE-SCHUKO

  • Net Volume: 271.2 lt

    External dimensions, Width: 1699 mm

    External dimensions, Depth: 700 mm

    External dimensions, Height: 1000 mm

    Internal Dimensions, Width: 1252 mm

    Internal Dimensions, Depth: 560 mm

    Internal Dimensions, Height: 550 mm

    Net weight: 140 kg

    Shipping volume: 1.61 m³

    Depth with doors open: 1110 mm

    Height adjustment: -5/50 mm

    Gross capacity: 440 lt

  • Control type: Digital

    Refrigeration power at evaporation temperature: -10 °C

    Min/Max internal humidity: 40/85

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Compressor power: 1/4 hp

    Operating mode: Ventilated

    Insulation: 90 mm (Cyclopentane)

  • Current consumption: 1.6 Amps

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 0 W

    Refrigerant weight (unit 1): 65 g

    Energy Class (EU Reg. 2015/1094): A

    Yearly and daily energy consumption (EU Reg. 2015/1094): 610kWh/year - 1.67kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 24.56

Product Features

Main Features

Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.
Anti-tilt runners accept GN 1/1 containers.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Frontal and easy access to all components in the cooling unit.
Certified safety CE requirements.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Small footprint to fit even in limited environments.
Self closing stainless steel doors (< 90°).
Digital control panel with temperature display.
Raised rear upstand permits unit to be connected up against the wall for better hygiene.
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Tropicalized unit.

Construction

3 compartments with 3 doors.
Internal and external structure in AISI 304 stainless steel. External back panel in galvanized steel and bottom in AISI 430 stainless steel as standard on all models.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Anti-drip profile on stainless steel worktop edge.
Interior base with rounded corners, pressed from a single sheet.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Built-in refrigeration unit.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Pre-arranged for drain-pipe.
Excellent space optimisation thanks to the compact dimensions.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Extractable cooling unit to facilitate maintenance.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.

Included Accessories

Quantity
Code
Description
Quantity: 3
Code: 881109
Kit 1/1 grey rilsan grid and 2 side runners for refrigerated counters
