Main Features
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Anti-tilt runners accept GN 1/1 containers.
Adjustable temperature range from -15 °C to -22 °C to suit meat, fish and dairy storage requirements.
Forced air circulation for rapid cooling and an even temperature distribution.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Frontal and easy access to all components in the cooling unit.
Digital control panel with temperature display.
Certified safety CE requirements.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Freezer compartment designed to accept GN1/1 containers.
Self closing stainless steel doors (< 90°).
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Tropicalized unit.
Sustainability
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Hot gas automatic evaporation of defrost water.
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
User Interface & Data Management
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Construction
Fault code display.
Internal dimension of the drawers.
• models with 2 1/2 drawers: 1st drawer (top drawer) 203x302x521 / 2nd drawer 223x302x521 (HxWxD)
• models with 3 1/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd and 3rd drawers 118x302x521 (HxWxD)
• models with 1/3+2/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd drawer 333x302x521 (HxWxD)
External back panel in galvanized steel.
Excellent space optimisation thanks to the compact dimensions.
Pre-arranged for drain-pipe.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Access to all components from the front.
External bottom panel in stainless steel.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Built-in refrigeration unit.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Rounded internal corners for ease of cleaning.
Built-in compressor to suit operating conditions.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Full stainless steel construction. Internal structure and worktop in AISI 304 Stainless steel.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Interior base with rounded corners, pressed from a single sheet.
Extractable cooling unit to facilitate maintenance.
Anti-drip profile on stainless steel worktop edge.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
