Main Features
Anti-tilt runners accept GN 1/1 containers.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Certified safety CE requirements.
Frontal and easy access to all components in the cooling unit.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Adjustable temperature range from -15 °C to -22 °C to suit meat, fish and dairy storage requirements.
Self closing stainless steel doors (< 90°).
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Self closing stainless steel doors (< 90°).
Certified safety CE requirements.
Adjustable temperature range from -15°C to -20°C to suit all storage requirements.
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Tropicalized unit.
Tropicalized unit.
Digital control panel with temperature display.
Forced air circulation for rapid cooling and an even temperature distribution.
Anti-tilt runners accept GN1/1 trays and grids.
Adjustable temperature range from -15°C to -20°C to suit all storage requirements.
Sustainability
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Hot gas automatic evaporation of defrost water.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
50 mm insulation thickness for energy saving.
User Interface & Data Management
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Construction
Extractable cooling unit to facilitate maintenance.
Excellent space optimisation thanks to the compact dimensions.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
External back panel in galvanized steel.
External bottom panel in stainless steel.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
3 compartments with 3 doors.
Fault code display.
Interior base with rounded corners, pressed from a single sheet.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Fault code display.
Built-in refrigeration unit.
Pre-arranged for drain-pipe.
External bottom panel in stainless steel.
External back panel in galvanized steel.
Access to all components from the front.
Constructed in Stainless steel with Scotch Brite finish to meet the highest hygiene standards.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Rounded internal corners for ease of cleaning.
304 AISI stainless steel internal and external doors, front and side panels. Evaporator in aluminium.
Pre-arranged for drain-pipe.
Built-in refrigeration unit.
