Main Features
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Certified safety CE requirements.
Frontal and easy access to all components in the cooling unit.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Hot gas automatic evaporation of defrost water.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Self closing stainless steel doors (< 90°).
Adjustable temperature range from -15 °C to -22 °C to suit meat, fish and dairy storage requirements.
Anti-tilt runners accept GN 1/1 containers.
Forced air circulation for rapid cooling and an even temperature distribution.
Digital control panel with temperature display.
Freezer compartment designed to accept GN1/1 containers.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Tropicalized unit.
Sustainability
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
User Interface & Data Management
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Construction
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Excellent space optimisation thanks to the compact dimensions.
Full stainless steel construction. Internal structure and worktop in AISI 304 Stainless steel.
External back panel in galvanized steel.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
Internal dimension of the drawers.
• models with 2 1/2 drawers: 1st drawer (top drawer) 203x302x521 / 2nd drawer 223x302x521 (HxWxD)
• models with 3 1/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd and 3rd drawers 118x302x521 (HxWxD)
• models with 1/3+2/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd drawer 333x302x521 (HxWxD)
External bottom panel in stainless steel.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Access to all components from the front.
Extractable cooling unit to facilitate maintenance.
Built-in compressor to suit operating conditions.
Pre-arranged for drain-pipe.
Anti-drip profile on stainless steel worktop edge.
Interior base with rounded corners, pressed from a single sheet.
Built-in refrigeration unit.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Rounded internal corners for ease of cleaning.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Fault code display.
