Main Features
Anti-tilt runners accept GN 1/1 containers.
Certified safety CE requirements.
Frontal and easy access to all components in the cooling unit.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Self closing stainless steel doors (< 90°).
Adjustable temperature range from -15 °C to -22 °C to suit meat, fish and dairy storage requirements.
Adjustable temperature range from -15 °C to -22 °C to suit meat, fish and dairy storage requirements.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Frontal and easy access to all components in the cooling unit.
Anti-tilt runners accept GN 1/1 containers.
Self closing stainless steel doors (< 90°).
Certified safety CE requirements.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Freezer compartment designed to accept GN1/1 containers.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Digital control panel with temperature display.
Forced air circulation for rapid cooling and an even temperature distribution.
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Tropicalized unit.
Tropicalized unit.
Freezer compartment designed to accept GN1/1 containers.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Digital control panel with temperature display.
Forced air circulation for rapid cooling and an even temperature distribution.
Sustainability
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Hot gas automatic evaporation of defrost water.
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
User Interface & Data Management
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Construction
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
External bottom panel in stainless steel.
Pre-arranged for drain-pipe.
Built-in refrigeration unit.
Anti-drip profile on stainless steel worktop edge.
2 compartments with 2 doors.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Fault code display.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
External back panel in galvanized steel.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Interior base with rounded corners, pressed from a single sheet.
Excellent space optimisation thanks to the compact dimensions.
Extractable cooling unit to facilitate maintenance.
2 compartments with 2 doors.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Anti-drip profile on stainless steel worktop edge.
Interior base with rounded corners, pressed from a single sheet.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Built-in refrigeration unit.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Pre-arranged for drain-pipe.
Excellent space optimisation thanks to the compact dimensions.
Built-in compressor to suit operating conditions.
Full stainless steel construction. Internal structure and worktop in AISI 304 Stainless steel.
Rounded internal corners for ease of cleaning.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Access to all components from the front.
Extractable cooling unit to facilitate maintenance.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
External bottom panel in stainless steel.
External back panel in galvanized steel.
Built-in compressor to suit operating conditions.
Full stainless steel construction. Internal structure and worktop in AISI 304 Stainless steel.
Rounded internal corners for ease of cleaning.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Access to all components from the front.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
