Main Features
The free zone induction offers the possibility to use multiple pots and pans, even small sizes (min diameter 7 cm), thanks to the multi-coil system design that makes all the surface active, ideal for à la carte menu.
The smooth glass-ceramic surface features limited temperature increase and it can be quickly and easily cleaned, thus providing maximum hygiene.
THERMODUL connection system creates a seamless work top when units are connected to each other thus avoiding soil penetrating vital components and facilitating the removal of units in case of replacement or service.
360° round stepless metal knobs, working clock and anticlock wise for quick parameters selection and adjustment.
Each zone is controlled by a touch-sensitive keypad with 7 touch buttons, 4 displays and a round knob. Each zone consistes in 4 coils, which can be individually controlled or bridged in 2, 3 or 4. Power (watts) or temperature (°C) can be selected. A function is also available to set and save 3 different configurations.
Power setting from 25 to 2000 watt in 30 steps or temperature settings from 30 to 250° C in steps of 1°C.
Electronic sensor, placed underneath the glass, below the coil center position, to precisly measure the temperature of the pan/pot bottom
Overheat protection: the temperature sensor switches off the supply in case of overheating.
Heating system automatically switches off when pots and pans are removed.
Low heat dissipation to the kitchen.
Cupboard door handle is ergonomically designed with silicon "soft" grip for easy handling and cleaning.
Sustainability
This model is compliant with Swiss Energy Efficiency Ordinance (730.02).
Construction
Cupboard door removable without tools for easy and efficient cleaning.
Unit constructed according to DIN 18860_2 with 20 mm drop nose top and 70 mm recessed plinth.
Flat surface construction with minimal hidden areas to easily clean all surfaces
Internal frame for heavy duty sturdiness in stainless steel.
All major components may be easily accessed from the front, including the induction filters.
2 mm top in 1.4301 (AISI 304).
34x72x33 cm (wxdxh) cupboard base with round corners H2 and door for storage.
IPX5 water resistance certification.
