Main Features
The center of the plate can reach a maximum temperature of 500 °C while decreasing outwards.
Burners with optimized combustion.
Oven thermostat adjustable from 120 °C to 280 °C.
Base compartment consists of a convection oven, with ON/OFF switch between static and convection mode, positioned beneath the base plate. Oven chamber to have 2 levels of runners to accomodate 2/1 GN shelves (2 steam pans) and ribbed enamelled steel base plate.
Piezo ignition.
The 6 kW and one 10 kW high efficiency flower flame burners are available in two different sizes to suit high performing cooking requirements of the most demanding customers: - 60 mm burners with power regulation from 1,5 to 6 kW - 100 mm burners with power regulation from 2.2 kW to 10 kW
Convection oven allows for simultaneous cooking on 2 levels thus reducing cooking times compared to standard static ovens (depending on food type).
Gas heated, 10.5 kW central burner, solid top.
Various sizes of pans can be used at the same time due to large surface area with no intermediate sectors.
The special design of the control knob system guarantees against water infiltration.
Temperature gradients to satisfy different cooking needs, provided over the whole plate thanks to the temperature fine-tuning by zone.
Pans can easily be moved from one area to another without lifting.
All major compartments located in front of unit for ease of maintenance.
Large sized pan support in cast iron (stainless steel as option) with long center fins to allow the use of the largest down to the smallest pans.
Flame failure device on each burner protects against gas leakage when accidental extinguishing of the flame occurs.
Cupboard compartment for storage of pots, pans, sheet pans etc.
Central burner with optimized combustion, flame failure device and protected pilot light.
Durable cast iron cooking plate, easy to clean.
All major compartments located in front of unit for ease of maintenance.
Durable cast iron cooking plate, easy to clean.
Central burner with optimized combustion, flame failure device and protected pilot light.
Cupboard compartment for storage of pots, pans, sheet pans etc.
Flame failure device on each burner protects against gas leakage when accidental extinguishing of the flame occurs.
Large sized pan support in cast iron (stainless steel as option) with long center fins to allow the use of the largest down to the smallest pans.
Pans can easily be moved from one area to another without lifting.
Temperature gradients to satisfy different cooking needs, provided over the whole plate thanks to the temperature fine-tuning by zone.
The center of the plate can reach a maximum temperature of 500 °C while decreasing outwards.
The special design of the control knob system guarantees against water infiltration.
Various sizes of pans can be used at the same time due to large surface area with no intermediate sectors.
Gas heated, 10.5 kW central burner, solid top.
The 6 kW and one 10 kW high efficiency flower flame burners are available in two different sizes to suit high performing cooking requirements of the most demanding customers: - 60 mm burners with power regulation from 1,5 to 6 kW - 100 mm burners with power regulation from 2.2 kW to 10 kW
Piezo ignition.
Burners with optimized combustion.
Oven thermostat adjustable from 120 °C to 280 °C.
Base compartment consists of a convection oven, with ON/OFF switch between static and convection mode, positioned beneath the base plate. Oven chamber to have 2 levels of runners to accomodate 2/1 GN shelves (2 steam pans) and ribbed enamelled steel base plate.
Convection oven allows for simultaneous cooking on 2 levels thus reducing cooking times compared to standard static ovens (depending on food type).
Construction
All exterior panels in Stainless Steel with Scotch Brite finishing.
Model has right-angled side edges to allow flush fitting joints between units, eliminating gaps and possible dirt traps.
IPX5 water resistance certification.
AISI 304 stainless steel worktop, 2mm thick.
Unit is 930 mm deep to give a larger working surface area.
Model has right-angled side edges to allow flush fitting joints between units, eliminating gaps and possible dirt traps.
IPX5 water resistance certification.
AISI 304 stainless steel worktop, 2mm thick.
All exterior panels in Stainless Steel with Scotch Brite finishing.
Unit is 930 mm deep to give a larger working surface area.
