Prostore 500 1 Door Digital Freezer, 470lt (-15/-22 °C) - R290 (COD 691352)

Compare Where to buy

Prostore Digital 500 liters (R290)

Prostore 500
1 Door Digital Freezer, 470lt (-15/-22 °C) - R290

COD 691352

1-door prostore Freezer 470lt, -15/-22°C, AISI 304, R290

Compare

Where to buy

Specifications

Electric

Supply voltage: 220-240 V/1 ph/50 Hz

Electrical power max.: 0.41 kW

Compressor power: 3/4 hp
Key Information

Number and type of grids (included): 5 (520x442)

Net Volume: 317 lt

External dimensions, Width: 600 mm

External dimensions, Depth: 700 mm

External dimensions, Depth with Doors Open: 1226 mm

External dimensions, Height: 2040 mm

Number and type of doors: 1 Full

Internal Dimensions, Width: 472 mm

Internal Dimensions, Depth: 582 mm

Internal Dimensions, Height: 1474 mm

Height adjustment: 15/40 mm

Type of external material: Stainless Steel AISI 304

Type of internal material: Stainless Steel AISI 304

Number of positions & pitch: 44; 22 mm

Gross capacity: 470 liter

Type of model: vertical freezer
Refrigeration Data

Control type: Digital

Refrigeration power at evaporation temperature: -30 °C

Operating temperature min.: -22 °C

Operating temperature max.: -15 °C

Operating mode: Ventilated

Cooling unit:

Defrost type: Electric
ISO Certificates

ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Type reference/certification group: P60MBTHC
Sustainability

Noise level: 54 dBA

Refrigerant type: R290

GWP Index: 3

Refrigeration power: 569 W

Refrigerant weight: 145 g

Energy Class (EU Reg. 2015/1094): D

Climate class (EU Reg. 2015/1094): Heavy Duty (5)

Energy Efficiency Index-EEI (EU Reg. 2015/1094): 69.21

Documents

Product Features

Main Features

Low noise level.

Complies with main international certification bodies and is CE marked.

Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.

Optimized airflow within the chamber guarantees uniformity of temperature on all grids.

Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Adjustable temperature range from -15°C to -22°C.

Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.

High resistance foot pedal included.

Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.

Large storage area suitable to contain 520x442 mm grids or shelves to improve net capacity.

Self closing and on site reversible left/right doors.

IPX5 frontal water protection.

Prearranged for remote alarm.

ECA listed.

This appliance is intended for use in ambient temperatures up to 40°C.

Tropicalized unit.

Sustainability

Optical door microswitch to stop the fan once the door is opened, thus minimizing energy waste.

Interior LED light to save energy and for best internal visibility.

Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

Frost Watch Control: fully automatic defrost starts only when ice is actually building-up in the evaporator and adapt the defrosting duration to guarantee perfect ice removal while optimizing energy efficiency consumption.

CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.

Insulation thickness: 65 mm of polyurethane injected with ecological foaming gas cyclopentane to ensure effective insulation with minimum energy consumption (thermal conductivity: 0,020 W/m*K).

User Interface & Data Management

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.

Large digital white-digit display with cabinet temperature display and setting. Bluetooth technology included allows to keep HACCP historical data and download them through the app.

Electrolux Professional Fridge Control APP makes the life easier for our customers: - Monitor safety of preservation process thanks to HACCP data & alarms for precise control- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address- Quick operations: set the cabinet temperature/turbocooling and set date/hour

Large digital white-digit display with cabinet temperature display and setting and turbo frost cycle (to rapidly cool warm loads).

Construction

Developed and produced in ISO 9001 and ISO 14001 certified factory.

Lockable door.

Inner cell with rounded corners, bottom pressed in only one piece.

Easy access to the main components for maintenance.

Stainless steel runners and supports easily disassembled.

Pressed stainless steel door handle without joints gathering dust and dirt.

Automatic heated door frame.

Stainless steel AISI 304 external panels (galvanized external back).

Internal components removable without the use of tools to facilitate cleaning operations.

Included Accessories


Quantity

Code

Description

Quantity: 1

Code: 880324

Pedal opening for cabinets

Quantity: 5

Code: 880335

Pair of runners for 470 and 720lt prostore cabinets

Quantity: 5

Code: 880342

Rilsan-coated grid 520x442mm for Prostore 470l

Detergents and Chemicals (not included)


Code

Description

Code: 0S2881

Code: 0S2883

Code: 0S2884

Code: 0S3257
