Digital Undercounter
ecostore HP Premium Refrigerated Counter - 290lt, 6x1/3 Drawers 710022
Where to buy

Digital Undercounter
ecostore HP Premium Refrigerated Counter - 290lt, 6x1/3 Drawers 710022

6x1/3 drawer Refrigerated Counter 290lt, -2+10°C, AISI 304

Where to buy

Product Features

  • CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.

  • Certified safety CE requirements.

  • Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

  • Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.

  • Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.

  • Large digital white-digit display with humidity selection button (3 preset level), internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).

  • Equipped with Optiflow forced air circulation system for rapid cooling and temperature distribution within the cell.

  • Tropicalized unit (43°C ambient temperature).

  • Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).

  • 0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.

  • Frost Watch Control starts automatically the defrosting process only when needed and ends once ice is melted, improving energy efficiency results.

  • Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.

  • Fully removable cooling unit to facilitate maintenance.

  • Frontal and easy access to all components in the cooling unit.

  • Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.

  • Anti-tilt runners accept GN 1/1 containers.

  • Self closing stainless steel doors (< 90°).

  • Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

  • Hot gas automatic evaporation of defrost water.

  • Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3) - CFC and HCFC free.

  • Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

  • Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.

  • External bottom panel in stainless steel.

  • External back panel in galvanized steel.

  • Interior base with rounded corners, pressed from a single sheet.

  • Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.

  • Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.

  • Internal dimension of the drawers.
    • models with 2 1/2 drawers: 1st drawer (top drawer) 203x302x521 / 2nd drawer 223x302x521 (HxWxD)

    • models with 3 1/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd and 3rd drawers 118x302x521 (HxWxD)

    • models with 1/3+2/3 drawers: 1st drawer (top drawer) 98x302x521 / 2nd drawer 333x302x521 (HxWxD)

  • Worktop in AISI 304 Stainless steel with a 50 mm profile.

  • If needed, working top can be removed for easier handling during installation (in case of narrow doors).

  • Anti-drip profile on stainless steel worktop edge.

  • Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.

  • Built-in refrigeration unit.

  • Developed and produced in ISO 9001 and ISO 14001 certified factory.

  • Fault code display.

Specifications

Electric
  • Supply voltage: 220-240 V/1 ph/50 Hz
  • Electrical power max.: 0.25 kW
  • Defrost Power: 0.22 kW
  • Current consumption: 1.8 Amps
  • Plug type: CE-SCHUKO
Product Information (EU Regulation 2015/1094)
  • Energy Class: B
  • Yearly and daily energy consumption: 683kWh/year - 2kWkWh/24h
  • Climate class: Heavy Duty (5)
  • Energy Efficiency Index (EEI): 33,64
Key Information:
  • Gross capacity: 290 lt
  • Net Volume: 94 lt
  • Door hinges:
  • External dimensions, Width: 1345 mm
  • External dimensions, Height: 900 mm
  • External dimensions, Depth: 700 mm
  • Internal Dimensions (depth): 560 mm
  • Internal Dimensions (height): 550 mm
  • Internal Dimensions (width): 798 mm
  • Net weight: 114 kg
  • Shipping volume: 1.13 m³
  • Depth with doors open: 1110 mm
  • Height adjustment: -5/50 mm
Refrigeration Data
  • Control type: Digital
  • Compressor power: 1/4 hp
  • Refrigerant type: R290
  • GWP Index: 3
  • Refrigeration power: 320 W
  • Refrigeration power at evaporation temperature: -10 °C
  • Refrigerant weight: 70 g
  • Min/Max internal humidity: 40/85
  • Operating temperature min.: -2 °C
  • Operating temperature max.: 10 °C
  • Operating mode: Ventilated
