Vacuum Packers Vacuum packer 12m3/h table top (COD 602179)
Where to buy
Table Top vacuum packers

Vacuum Packers
Vacuum packer 12m3/h table top

COD 602179

Vacuum Packer, 12 m3/h, table top, digital display

Specifications

  • Supply voltage: 220/240 V/1N ph/50-60 Hz

    Total Watts: 0.7 kW

    Plug type: CE-SCHUKO

  • Well Capacity: 19 lt

    Pump: 12 m³/h

    Capacity: 19 kg

    Sealing bar position: Front

    Sealing bar length: 310 mm

    Max chamber (chamber + cover) dimensions: 434 x 343 x 175 mm

    Chamber working dimensions: 382 x 343 x 135 mm

    Filling board nr: 2

    Gas nozzles: 2

    External dimensions, Width: 415 mm

    External dimensions, Depth: 587 mm

    External dimensions, Height: 437 mm

    Net weight (kg): 46.5

Product Features

Table-top vacuum packer with oil lubricated vacuum pump.
Vacuum level control through high-precision, absolute-type vacuum sensor, which does not require calibration.
Pressure chamber made of constant thickness, hydroformed, stainless steel with rounded corners for easy cleaning.
Sturdy, transparent PMMA (plexiglass) lid with rounded edges; opens automatically at the end of the cycle.
Control panel, resistant to liquids, humidity, dirt and dust.
10 editable user programs (vacuum, extra vacuum, sealing time, gas percentage).
1 vacuum cycle for jars/containers.
1 adjustable deaeration cycle.
Adjustable sealing time 0.1 to 6 seconds.
Specific pump oil cleaning cycle (H2Out).
Automatic warnings if food needs cooling down (hot), failure in the packing process, gas missing, oil change.
Pre-arranged for external vacuum packing in containers by connecting a specific pipe to the air extraction nozzle (available as spare part).
2 PE filling plates included.
Sealing bar 310 mm, easily removable for cleaning.
Unit pre-arranged to be connected to an inert gas system.
Entirely constructed in 304 AISI stainless steel.
Easy access for service through hinged opening of the body.
