Green&Clean Hood Type Dishwasher, Manual with ZERO LIME Device & CLEAR BLUE System 504262
Dishwasher, hood type, 60 racks/hour, hot water sanitizing with built-in booster heater, field convert corner/straight thru, 304 stainless steel frame, wash tank, booster tank & side panels, drain, detergent & rinse aid pumps, 240v/60/3-ph, 24 amps, 2 HP,
Product Features
-
Maximum capacity per hour of 80 racks or 1.440 dishes.
-
The machine can be connected to cold water**.
-
CLEAR BLUE advanced filtering system provides cleaner wash water and higher active detergent thus ensuring better washing performances and lower running costs.
-
ETL-Sanitation approved (ANSI/NSF 3 sanitation standard) and DIN 10512 compliant.
-
Requires only 0.6gal (2 liters) of water per washing cycle thus ensuring low energy, water, detergent and rinse aid consumption.
-
Built-in atmospheric boiler sized to raise incoming water to a minimum of 183 °F (84 °C) for sanitizing rinse. No external booster is required. Constant temperature of 183 °F (84 °C) throughout the rinsing cycle regardless of the network's water pressure.
-
Green light of "WASH SAFE CONTROL" confirms that items have been rinsed properly.
-
Unique temperature interlock guarantees required temperatures in both the wash and final rinse.
-
Incorporated Soft Start feature to offer additional protection to more delicate items.
-
Slanted wash arms and sloped ceiling to avoid detergent-filled wash water dropping on clean dishes after the rinsing phase, thus guaranteeing ideal washing results.
-
Cycle may be interrupted at any time by lifting the hood.
-
Automatic self-cleaning cycle and self-draining vertical wash pump and boiler to avoid bacteria proliferation.
-
State-of-the-art electronic controls with built-in programming, self-diagnostics for serviceability and automatic interior self-cleaning cycle.
-
Built-in rinse aid and detergent dispenser with automatic initial and continuous cycle loading for perfect result while minimizing service and maintenance needs.
-
IP25 protection against water jet, solid objects and small animals (larger than 0.2").
-
Heavy duty Stainless steel construction. Internal cavity as well as exterior panels are in 304 series Stainless steel.
-
Pressed tank in front position to facilitate cleaning.
-
Double skin insulated hood.
-
Specially designed Stainless steel wash/rinse arms and nozzles provide superior cleaning action.
-
Revolving interchangeable Stainless steel wash/rinse arms above and below the rack, screw out for simple clean up.
-
Pre-arranged for on-site HACCP implementation and Energy Management device.
-
Element protection from dry fire and low water.
-
Unit to include drain pump and rinse aid dispenser pump.
Specifications
Key Information:
- Wash temperature (MIN): 160°F (71°C)
- N° of cycles: 3
- Duration cycle - NSF:* 57/84/150 sec.
- Racks per hour - ETL-S: * 63
- Dishes per hour - ETL-S: * 1134
- Rinse temperature (MIN): 183.2°F (84°C)
- External dimensions, Width: 29 5/8" (752 mm)
- External dimensions, Depth: 29 3/4" (755 mm)
- External dimensions, Height: 61 11/16" (1567 mm)
- Net weight: 258 lbs (117 kg)
- Shipping width: 36 1/4" (920 mm)
- Shipping depth: 30 5/16" (770 mm)
- Shipping height: 67 3/4" (1730 mm)
- Shipping weight: 317 lbs (144 kg)
- Shipping volume: 43.02 ft³ (1.23 m³)
- Noise level: <63 dBA
-
* According to market standard, the productivity is declared at an inlet water supply temperature of 122°F (50°C) and does not include loading/unloading time.
Water:
- Water supply temperature: 50-122°F (10-50 °C)
- Inlet Water supply pressure: 7 - 102 psi (0.5 - 7 bar)
- Peak Rate of Drain Flow: 0 l/s
- Water consumption per cycle: 0.53 gal (2 L)
- Booster Capacity: 3.17 gal (12 L)
- Tank Capacity: 6.34 gal (24 L)
- Drain line size: 0.8'' (20.5 mm) pumped drain
Electric
- Supply voltage: 240 V/3 ph/60 Hz
- Required Amps (Min; MOP, MCA): 24A; 40A, 34A
- Default Installed Power: 9.9 kW at 50°F (10°C)
- Booster Heating Elements Power: 9 kW at 50°F (10°C)
- Tank heating elements: 3 kW
- Wash pump power: 1.1 hp (0.8 kW)
