Digital Undercounterecostore HP Premium Freezer Counter - 290lt, 2-Door (COD 710288)
Where to buy
ecostore HP Premium Freezer Counters - 2 comp. with top

Digital Undercounter
ecostore HP Premium Freezer Counter - 290lt, 2-Door

COD 710288

2-door Freezer Counter 290lt, -22-15°C, AISI 304

Product Features

    • Adjustable temperature range from -15°C to -22°C.
    • Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
    • External back panel and bottom panel in AISI 304.
    • Equipped with Optiflow forced air circulation system for rapid cooling and temperature distribution within the cell.
    • Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
    • Frost Watch Control starts automatically the defrosting process only when needed and ends once ice is melted, improving energy efficiency results.
    • Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
    • Fully removable cooling unit to facilitate maintenance.
    • Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
    • Self closing stainless steel doors (< 90°).
    • Hot gas automatic evaporation of defrost water.
    • Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
    • 2 compartments with 2 doors.
    • Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
    • If needed, working top can be removed for easier handling during installation (in case of narrow doors).
    • Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
    • Developed and produced in ISO 9001 and ISO 14001 certified factory.
    • Mounted on Stainless steel legs to give 150 mm clearance for ease of cleaning the floor.
    • CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest
      environmental impact (GWP=3), to reduce green house and ozone depletion effects.
    • Certified safety CE requirements.
    • Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
    • Tropicalized unit (43°C ambient temperature).
    • 0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows
      installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
    • Frontal and easy access to all components in the cooling unit.
    • Anti-tilt runners accept GN 1/1 containers.
    • Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
    • Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3) - CFC and HCFC free.
    • Interior base with rounded corners, pressed from a single sheet.
    • Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
    • Worktop in AISI 304 Stainless steel with a 50 mm profile.
    • Anti-drip profile on stainless steel worktop edge.
    • Built-in refrigeration unit.
    • Fault code display.

    Specifications

    • Supply voltage: 220-240 V/1 ph/50 Hz

      Electrical power max.: 0.49 kW

      Defrost Power: 0.57 kW

      Current consumption: 3.3 Amps

      Plug type: CE-SCHUKO

    • Gross capacity: 290 lt

      Net Volume: 198 lt

      Door hinges: 1 Left+1 Right

      External dimensions, Width: 1345 mm

      External dimensions, Height: 900 mm

      External dimensions, Depth: 700 mm

      Internal Dimensions (depth): 560 mm

      Internal Dimensions (height): 550 mm

      Internal Dimensions (width): 798 mm

      Net weight: 105 kg

      Shipping volume: 1.13 m³

      Depth with doors open: 1110 mm

      Height adjustment: -5/50 mm

    • Energy Class: C

      Yearly and daily energy consumption: 1564kWh/year - 4kWkWh/24h

      Climate class: Heavy Duty (5)

      Energy Efficiency Index (EEI): 44,23

    • Control type: Digital

      Compressor power: 3/4 hp

      Refrigerant type: R290

      GWP Index: 3

      Refrigeration power: 569 W

      Refrigeration power at evaporation temperature: -30 °C

      Refrigerant weight: 145 g

      Min/Max internal humidity:

      Operating temperature min.: -15 °C

      Operating temperature max.: -22 °C

      Operating mode: Ventilated
