ecostore HP Premium Freezer Counter - 290lt, 2-Door 710288
Adjustable temperature range from -15°C to -22°C.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
Certified safety CE requirements.
External back panel and bottom panel in AISI 304.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Equipped with Optiflow forced air circulation system for rapid cooling and temperature distribution within the cell.
Tropicalized unit (43°C ambient temperature).
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Frost Watch Control starts automatically the defrosting process only when needed and ends once ice is melted, improving energy efficiency results.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Fully removable cooling unit to facilitate maintenance.
Frontal and easy access to all components in the cooling unit.
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Anti-tilt runners accept GN 1/1 containers.
Self closing stainless steel doors (< 90°).
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Hot gas automatic evaporation of defrost water.
Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3) - CFC and HCFC free.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Interior base with rounded corners, pressed from a single sheet.
2 compartments with 2 doors.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Anti-drip profile on stainless steel worktop edge.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Built-in refrigeration unit.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Mounted on Stainless steel legs to give 150 mm clearance for ease of cleaning the floor.
- Supply voltage: 220-240 V/1 ph/50 Hz
- Electrical power max.: 0.49 kW
- Defrost Power: 0.57 kW
- Current consumption: 3.3 Amps
- Plug type: CE-SCHUKO
Product Information (EU Regulation 2015/1094)
- Energy Class: C
- Yearly and daily energy consumption: 1564kWh/year - 4kWkWh/24h
- Climate class: Heavy Duty (5)
- Energy Efficiency Index (EEI): 44,23
- Gross capacity: 290 lt
- Net Volume: 198 lt
- Door hinges: 1 Left+1 Right
- External dimensions, Width: 1345 mm
- External dimensions, Height: 900 mm
- External dimensions, Depth: 700 mm
- Internal Dimensions (depth): 560 mm
- Internal Dimensions (height): 550 mm
- Internal Dimensions (width): 798 mm
- Net weight: 105 kg
- Shipping volume: 1.13 m³
- Depth with doors open: 1110 mm
- Height adjustment: -5/50 mm
- Control type: Digital
- Compressor power: 3/4 hp
- Refrigerant type: R290
- GWP Index: 3
- Refrigeration power: 569 W
- Refrigeration power at evaporation temperature: -30 °C
- Refrigerant weight: 145 g
- Min/Max internal humidity:
- Operating temperature min.: -15 °C
- Operating temperature max.: -22 °C
- Operating mode: Ventilated
- Range overviews
- Data Sheet
- Eco Guide
- Energy Label
