Digital Undercounter ecostore HP Refrigerated Counter - 2 Door (R290) (COD 710405)
Where to buy
ecostore HP Refrigerated Counters - 2 comp. - No top

Digital Undercounter
ecostore HP Refrigerated Counter - 2 Door (R290)

COD 710405

2-door Refrigerated Counter -2+10°C, AISI 304 (R290), without work top

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.22 kW

  • Gross capacity: 290 lt

    Net Volume: 163.6 lt

    N° of doors:

    External dimensions, Width: 1241 mm

    External dimensions, Depth: 700 mm

    External dimensions, Height: 800 mm

    Internal Dimensions, Width: 798 mm

    Internal Dimensions, Depth: 560 mm

    Internal Dimensions, Height: 510 mm

    Net weight: 90 kg

    Shipping volume: 1.03 m³

    Depth with doors open: 1310 mm

  • Energy Class (EU Reg. 2015/1094): B

    Yearly and daily energy consumption (EU Reg. 2015/1094): 560kWh/year - 2kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 25,36

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 320 W

    Refrigerant weight: 50 g

  • Control type: Digital

    Compressor power: 1/4 hp

    Min/Max internal humidity: 40/85

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Operating mode: Ventilated

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Product Features

Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Kit 1/3 drawers available as accessory.
Easy serviceability thanks to the intuitive control panel with remote access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Digital control panel allowing the easy and precise setting and control of the internal temperature.
Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.
Complies with main international certification bodies and is CE marked.
Kit 1/2 drawers available as accessory.
The door self-closes when opened less than at a 90° angle and is equipped with a door seal to guarantee perfect closure.
Completely automatic defrosting and automatic evaporation of defrost water by hot gas.
Forced air cooling system guaranteeing great uniformity of the temperature in the counter and excellent conservation of the food quality.
High standards of hygiene and ease of cleaning are guaranteed by the rounded internal corners of the cabinet and easily removable runners and grids.
External back panel in galvanized steel.
Built-in compressor to suit operating conditions.
CFC and HCFC free.
Legs in 304 AISI stainless steel (150 mm high, adjustable in height), with plastic interior.
Internal and external doors, front and side panels in 304 AISI stainless steel.
