Digital Undercounter ecostore HP Premium Refrigerated Counter - 440lt, 3-Door, Upstand (COD 710029)
Where to buy
Digital Undercounterecostore HP Premium Refrigerated Counter - 440lt, 3-Door, Upstand
ecostore HP Premium

Digital Undercounter
ecostore HP Premium Refrigerated Counter - 440lt, 3-Door, Upstand

COD 710029

3-door Refrigerated Counter 440lt, -2+10°C, AISI 304, with splashback

Fast range available in stock. (click to discover more)

Where to buy
Product registration

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Defrost Power: 0.22 kW

    Plug type: CE-SCHUKO

    Compressor power: 1/4 hp

  • Net Volume: 310 lt

    External dimensions, Width: 1799 mm

    External dimensions, Depth: 700 mm

    External dimensions, Height: 1000 mm

    Internal Dimensions, Width: 1252 mm

    Internal Dimensions, Depth: 560 mm

    Internal Dimensions, Height: 550 mm

    Net weight: 128 kg

    Shipping volume: 1.61 m³

    Depth with doors open: 1110 mm

    Height adjustment: -5/50 mm

    Gross capacity: 440 liter

  • Control type: Digital

    Refrigeration power at evaporation temperature: -10 °C

    Min/Max internal humidity: 40/85

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Operating mode: Ventilated

    Insulation: 90 mm (Cyclopentane)

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

    Type reference/certification group: H7NTN3BHC

  • Refrigerant type: R290

    Refrigeration power: 320 W

    Refrigerant weight: 70 g

    Energy Class (EU Reg. 2015/1094): A

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 21,69

Product Features

Main Features

Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.
Anti-tilt runners accept GN 1/1 containers.
Raised rear upstand permits unit to be connected up against the wall for better hygiene.
Self closing stainless steel doors (< 90°).
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
Equipped with Optiflow forced air circulation system for rapid cooling and temperature distribution within the cell.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Fully removable cooling unit to facilitate maintenance.
Frontal and easy access to all components in the cooling unit.
Certified safety CE requirements.
Tropicalized unit.

Sustainability

Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.
Frost Watch Control starts automatically the defrosting process only when needed and ends once ice is melted, improving energy efficiency results.
Top energy efficiency (class A) and granted uniformity even at extreme working conditions (class 5; 40°C and 40% humidity): unbeatable performance, certified by energy test protocol EN16825:2016.
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3) - CFC and HCFC free.
Hot gas automatic evaporation of defrost water.

User Interface & Data Management

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Large digital white-digit display with cabinet temperature display and setting, and possibility to select the desired levels of humidity. Bluetooth technology included allows to keep HACCP historical data and download them through the app.
Electrolux Professional Fridge Control APP makes the life easier for our customers: ​- Monitor safety of preservation process thanks to HACCP data & alarms for precise control​​- Save time and easy data management having the possibility to send the HACCP information in excel format directly to e-mail address​- Quick operations:​ set the cabinet temperature/humidity/turbocooling​ and set date/hour
Large digital white-digit display with humidity selection button (3 preset level), internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).

Connect the product (with accessory) to the OneConnected Platform via Wi Fi or ethernet connection for a seamless remote experience. Real-time monitoring and analytics, alarm management, HACCP data management, APIs, and advanced features keep your fridge fully under control.

Construction

Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Interior base with rounded corners, pressed from a single sheet.
Internal and external doors, front and side panels and removable worktop in AISI 304 Stainless steel.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Built-in refrigeration unit.
Anti-drip profile on stainless steel worktop edge.
3 compartments with 3 doors.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
External bottom panel in stainless steel.
External back panel in galvanized steel.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.

Included Accessories

Quantity
Code
Description
Quantity: 3
Code: 881109
Kit 1/1 grey rilsan grid and 2 side runners for refrigerated counters

Detergents and Chemicals (not included)

Code
Description
Code: 0S2881
Shop now
Code: 0S2883
Shop now
Code: 0S2884
Shop now
S04 Glasses & Hard Surfaces Cleaner, 6 x 750ml bottles
Code: 0S3257
Shop now
