ecostore 1 Door Digital Refrigerator, 670lt (-2/+10), AISI 304 (R290) (COD 725321)
Where to buy
ecostore1 Door Digital Refrigerator, 670lt (-2/+10), AISI 304 (R290)
ecostore

ecostore
1 Door Digital Refrigerator, 670lt (-2/+10), AISI 304 (R290)

COD 725321

1-door Refrigerator 670lt, -2+10°C, digital, AISI 304, R290

Fast range available in stock. (click to discover more)

Where to buy
Product registration

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

  • Number and type of grids (included): 3 (GN 2/1)

    Net Volume: 503 lt

    External dimensions, Width: 710 mm

    External dimensions, Depth: 835 mm

    External dimensions, Depth with Doors Open: 1480 mm

    External dimensions, Height: 2050 mm

    Number and type of doors: 1 Full

    Type of external material: Stainless Steel AISI 304

    Type of internal material: Stainless Steel AISI 304

    Internal panels material: Stainless Steel AISI 304

    Number of positions & pitch: 44; 30 mm

    Gross capacity: 670 liter

    Type of model: Vertical chilled

  • Control type: Digital

    Refrigeration power at evaporation temperature: -10 °C

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Operating mode: Ventilated

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

    Type reference/certification group: V1MMTNHC

  • Refrigerant type: R290

    Refrigeration power: 278 W

    Refrigerant weight: 70 g

    Energy Class (EU Reg. 2015/1094): C

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 49,67

Product Features

Main Features

Automatic defrost.
Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.
Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.
Right hinged full door.
Cabinet fitted with up to 75 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Internal structure with numerous charging positions available to host grids, ensuring higher net capacity and a greater storage space.
60 mm-thick insulation covering the evaporator can be easily removed with a single operation.
Optimized back to front forced air flow provide even temperature distribution and fast cooling in any conditions.
Equipped with single phase electrical cable and Schuko plug for easy and fast installation.
Tropicalized unit.

Sustainability

Automatic evaporation of the defrosting water by hot gas on the top for energy saving.
Cleaning-free condenser: the structure of the wire frame condenser prevents dust and grease accumulation thus avoiding periodical cleaning operations and reducing energy consumption.
Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.

User Interface & Data Management

Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Connect the product (with accessory) to the OneConnected Platform via Wi Fi or ethernet connection for a seamless remote experience. Real-time monitoring and analytics, alarm management, HACCP data management, APIs, and advanced features keep your fridge fully under control.

Construction

Lockable door.
Mounted on adjustable Stainless steel feet, with castors as an option.
The rounded internal corners, the easily removable runners and grids allow for ease of cleaning and high hygiene standards.
Constructed from the highest quality AISI 304 Stainless steel.
Easy access to the main components for maintenance.
Stainless steel runners and supports easily disassembled.
Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.
Doors are self-closing and can be fully opened up to 180°.

Included Accessories

Quantity
Code
Description
Quantity: 3
Code: 881020
2/1GN grey rilsan grid with 2 runners

Detergents and Chemicals (not included)

Code
Description
Code: 0S2881
Shop now
Code: 0S2883
Shop now
Code: 0S2884
Shop now
S04 Glasses & Hard Surfaces Cleaner, 6 x 750ml bottles
Code: 0S3257
Shop now
