ecostore HPe 1 Door Freezer 670lt, pressed guides and light, -22 -15, Class B (COD 725670)

Sammenlign Her kan du købe vores produkter

ecostore HPe 670 liters Digital Freezers (R290)

ecostore HPe
1 Door Freezer 670lt, pressed guides and light, -22 -15, Class B

COD 725670

1-door Freezer 670lt, -22-15°C, pressed guides, digital, AISI 304, with internal light, R290, Class B

Sammenlign

Her kan du købe vores produkter

Specifikationer

Electric

Supply voltage: 220-240 V/1 ph/50 Hz

Electrical power max.: 0.3 kW

Compressor power: 1 hp
Key Information

Number and type of grids (included): 3 (GN 2/1)

Net Volume: 496 lt

External dimensions, Width: 740 mm

External dimensions, Depth: 860 mm

External dimensions, Depth with Doors Open: 1480 mm

External dimensions, Height: 2080 mm

Number and type of doors: 1 Full

Type of external material: Stainless Steel AISI 304

Type of internal material: Stainless Steel AISI 304

Internal panels material: Stainless Steel AISI 304

Number of positions & pitch: 24; 55 mm

Gross capacity: 670 liter

Type of model: vertical freezer
Refrigeration Data

Control type: Digital

Refrigeration power at evaporation temperature: -30 °C

Operating temperature min.: -22 °C

Operating temperature max.: -15 °C

Operating mode: Ventilated
ISO Certificates

ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Type reference/certification group: V1MMHBTHC
Sustainability

Refrigerant type: R290

GWP Index: 3

Refrigeration power: 322 W

Refrigerant weight: 85 g

Energy Class (EU Reg. 2015/1094): B

Climate class (EU Reg. 2015/1094): Heavy Duty (5)

Energy Efficiency Index-EEI (EU Reg. 2015/1094): 34.98

Dokumenter

Produktegenskaber

Main Features

Combining outstanding energy efficiency with reliable performance, the HPe range stands out thanks to its innovative pressed guides design and refined ergonomics.

Freezer model has operating temperatures that can be adjusted from -22 to -15 °C.

Multi-directional Optiflow system ensures consistent cooling distribution throughout the cabinet, even at full capacity; it is enabled by the vertical optimized spacing between guides, which facilitates unobstructed air circulation (Patent Pending - EP25203398.0).

Cabinet fitted with up to 90 mm thickness of cyclopentane insulation for best insulating performance with 100% environmental protection (thermal conductivity: 0,020 W/m*K).

Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.

Tropicalized unit.

Large storage area suitable to contain 2/1 GN grids or shelves on anti-tilt runners.

Automatic defrost.

Equipped with single phase electrical cable and Schuko plug for easy and fast installation.

Right hinged full door.

Sustainability

Automatic evaporation of the defrosting water by hot gas on the top for energy saving.

Door switch stops the fan when door is opened to avoid cold air exiting the cell, thus saving energy.

Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.

CFC and HCFC free, highly ecological refrigerant type: R290 (ecological gas in foam: cyclopentane). Hydrocarbon refrigerant gas R290 for the lowest environmental impact (GWP=3), to reduce green house and ozone depletion effects.

User Interface & Data Management

Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.

Easy serviceability thanks to the intuitive control panel with access via app.

Large digital white-digit display with cabinet temperature display and setting, activation of turbo frost cycle (to rapidly cool warm loads) and possibility to activate manually the defrost cycle.

Connect the product (with accessory) to the OneConnected Platform via Wi Fi or ethernet connection for a seamless remote experience. Real-time monitoring and analytics, alarm management, HACCP data management, APIs, and advanced features keep your fridge fully under control.

Construction

The one-piece pressed guides, together with rounded internal corners, ensure fast and hygienic cleaning to the highest standards.

Easy access to the main components for maintenance.

Anti-corrosion bottom material avoids any damage that may be caused to the cabinet by aggressive detergents employed to clean the floors.

Doors are self-closing and can be fully opened up to 180°.

Lockable door.

Mounted on adjustable Stainless steel feet, with castors as an option.

Included Accessories


Quantity

Code

Description

Quantity: 3

Code: 881004

2/1GN grey rilsan grid

Detergents and Chemicals (not included)


Code

Description

Code: 0S2881

Code: 0S2883

Code: 0S2884

Code: 0S3257
