Main Features
Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.
Anti-tilt runners accept GN 1/1 containers.
Combination of doors and drawers to suit varying needs, with the possibility to change the configuration on site.
Digital control panel allowing the easy and precise setting and control of the internal temperature.
Digital control panel.
Forced air circulation for rapid cooling and an even temperature distribution.
Operating temperature can be adjusted from -2 to +10 °C to suit different food storage requirements.
Refrigerated compartment designed to accept GN 1/1 containers.
Complies with main international certification bodies and is CE marked.
Self closing stainless steel doors (< 90°).
Kit 1/2 drawers available as accessory.
Forced air cooling system guaranteeing great uniformity of the temperature in the counter and excellent conservation of the food quality.
Completely automatic defrosting.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Preservation performances and temperature uniformity within the cell guaranteed at 5-HEAVY DUTY (40°C) working conditions according to EN16825:2016 test protocol.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Frontal and easy access to all components in the cooling unit.
Certified safety CE requirements.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Digital white-digit display with internal temperature display and setting, manual activation of defrost cycle and turbo frost cycle (to rapidly cool warm loads).
Tropicalized unit.
Sustainability
Removable triple-chamber balloon magnetic gasket to improve insulation and reduce energy consumption and ease of cleaning.
Top energy efficiency (class A) and granted uniformity even at extreme working conditions (class 5; 40°C and 40% humidity): unbeatable performance, certified by energy test protocol EN16825:2016.
Fitted with 90 mm thickness of cyclopentane insulation for best insulating performance (thermal conductivity: 0,020 W/m*K) and lowest environmental impact (GWP=3).
Hot gas automatic evaporation of defrost water.
User Interface & Data Management
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Easy serviceability thanks to the intuitive control panel with access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Connect the product (with accessory) to the OneConnected Platform via Wi Fi or ethernet connection for a seamless remote experience. Real-time monitoring and analytics, alarm management, HACCP data management, APIs, and advanced features keep your fridge fully under control.
Construction
Access to all components from the front.
Built-in compressor to suit operating conditions.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Interior base with rounded corners, pressed from a single sheet.
Internal and external doors, front, back and side panels in AISI 304 Stainless steel.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Remote refrigeration unit.
Rounded internal corners for ease of cleaning.
Pre-arranged for drain-pipe.
Built-in refrigeration unit.
Legs in 304 AISI stainless steel (150 mm high, adjustable in height), with plastic interior.
The door self-closes when opened less than at a 90° angle and is equipped with a door seal to guarantee perfect closure.
High standards of hygiene and ease of cleaning are guaranteed by the rounded internal corners of the cabinet and easily removable runners and grids.
Insulation guaranteed by high density expanded cyclopenthane 50 mm in thickness.
Internal and external doors, front and side panels and 50mm thick removable worktop in 304 AISI stainless steel.
Back panel in galvanized steel.
2 compartments with 2 doors.
External bottom panel in stainless steel.
External back panel in galvanized steel.
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Excellent space optimisation thanks to the compact dimensions.
Extractable cooling unit to facilitate maintenance.
