Digital Undercounter ecostore HP Concept Refrigerated Counter with Splashback - 2 Door (R290) (COD 714497)
Where to buy
ecostore HP Concept Refrigerated Counters - 2 comp. with top and upstand

Digital Undercounter
ecostore HP Concept Refrigerated Counter with Splashback - 2 Door (R290)

COD 714497

2-door Refrigerated Counter, -2+10°C, AISI 304 (R290), with splashback

Specifications

  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.22 kW

  • Gross capacity: 290 lt

    Net Volume: 180.8 lt

    N° of doors: 2

    Built-in Compressor and Refrigeration Unit

    External dimensions, Width: 1245 mm

    External dimensions, Depth: 700 mm

    External dimensions, Height: 1000 mm

    Internal Dimensions, Width: 798 mm

    Internal Dimensions, Depth: 560 mm

    Internal Dimensions, Height: 550 mm

    Net weight: 114 kg

    Shipping volume: 1.21 m³

    Depth with doors open: 1110 mm

  • Energy Class (EU Reg. 2015/1094): A

    Yearly and daily energy consumption (EU Reg. 2015/1094): 482kWh/year - 1kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 21,40

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 0 W

    Refrigerant weight: 50 g

  • Control type: Digital

    Compressor power: 1/4 hp

    Min/Max internal humidity: 40/85

    Operating temperature min.: -2 °C

    Operating temperature max.: 10 °C

    Operating mode: Ventilated

  • ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Product Features

Digital control panel with temperature display.
Raised rear upstand permits unit to be connected up against the wall for better hygiene.
Easy serviceability thanks to the intuitive control panel with remote access via app.
Integrated RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Adjustable temperature range from -2 °C to +10 °C to suit meat, fish and dairy storage requirements.
Anti-tilt runners accept GN 1/1 containers.
Self closing stainless steel doors (< 90°).
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
0mm clearance installation space: tower configuration cooling unit guarantee performance with frontal ventilation only; this unique solution allows installation against the wall or side by side with other appliances, even on the cooling unit side to maximize the use of kitchen space.
Hot gas automatic evaporation of defrost water.
Combination of doors and drawers to suit any configuration needed, with the possibility to change the configuration on site. Right cooling unit available on request.
Frontal and easy access to all components in the cooling unit.
Mounted on stainless steel feet to give 150 mm (-5/+50 mm) clearance for ease of cleaning the floor.
Certified safety CE requirements.
Equipped with forced air circulation system for rapid cooling and temperature distribution within the cell.
Small footprint to fit even in limited environments.
Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Ease of cleaning and high hygiene standards thanks to the rounded internal corners, the easily removable runners, grids and air conveyors.
Internal and external structure in AISI 304 stainless steel. External back panel in galvanized steel and bottom in AISI 430 stainless steel as standard on all models.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Fault code display.
Interior base with rounded corners, pressed from a single sheet.
Mounted on Stainless steel adjustable legs to give 150 mm clearance for ease of cleaning.
Worktop in AISI 304 Stainless steel with a 50 mm profile.
Pre-arranged for drain-pipe.
Built-in refrigeration unit.
Anti-drip profile on stainless steel worktop edge.
2 compartments with 2 doors.
If needed, working top can be removed for easier handling during installation (in case of narrow doors).
Internal structure with 15 charging positions (3 cm pitch) available to host GN 1/1 grids, ensuring higher net capacity and a greater storage space.
Excellent space optimisation thanks to the compact dimensions.
Extractable cooling unit to facilitate maintenance.
