Modular Cooking Range Line
700XP 2-Burner Gas Boiling Top 371000
2-Burner (5,5 kW each) gas Boiling Top
Product Features
Unit to be mounted on open base cupboards, bridging supports or cantilever systems.
The two 5.5 kW high efficiency flower flame burners allow the flame to adapt to different size pans.
Gas appliance supplied for use with natural or LPG gas, conversion jets supplied as standard.
Large sized pan support in cast iron (stainless steel as option) with long center fins to allow the use of the largest down to the smallest pans.
Pan supports in cast iron are washable in a dishwasher.
Burners to feature flame regulator.
Flame failure device on each burner protects against gas leakage when accidental extinguishing of the flame occurs.
Protected pilot light.
IPx4 water protection.
All exterior panels in Stainless Steel with Scotch Brite finishing.
One piece pressed 1.5 mm work top in Stainless steel.
Model has right-angled side edges to allow flush fitting joints between units, eliminating gaps and possible dirt traps.
Specifications
Gas
- Gas Power: 11 kW
- Standard gas delivery: Natural Gas G20 (20mbar)
- Gas Type Option: LPG;Natural Gas;Town
- Gas Inlet: 1/2"
Key Information:
- Front Burners Power: 5.5 - kW
- Back Burners Power: 5.5 - 0 kW
- Back Burners Dimension - mm Ø 60
- Front Burners Dimension - mm Ø 60
- External dimensions, Width: 400 mm
- External dimensions, Height: 250 mm
- External dimensions, Depth: 730 mm
- Net weight: 20 kg
- Shipping weight: 28 kg
- Shipping height: 530 mm
- Shipping width: 460 mm
- Shipping depth: 800 mm
- Shipping volume: 0.2 m³
- Certification group: N7CG
Documents
- Brochures
- Range overviews
- CAD Drawings
- Data Sheet
- User Maintenance
- BIM/Revit
