Digital Cabinets Digital Ice-cream Preserver 1 Door 720lt (-28/-12) (COD 691357)
Where to buy
Prostore Digital 880 liters Ice Cream (R290)

Digital Cabinets
Digital Ice-cream Preserver 1 Door 720lt (-28/-12)

COD 691357

1-door Ice Cream Preserver 720lt, -28/-12°C, AISI 304, R290


  • Supply voltage: 220-240 V/1 ph/50 Hz

    Electrical power max.: 0.45 kW

  • Gross capacity: 720 lt

    Net Volume: 526 lt

    Door hinges: Right Side

    External dimensions, Width: 900 mm

    External dimensions, Depth with Doors Open: 1527 mm

    External dimensions, Height: 2040 mm

    Number and type of doors: 1 Full

    Number and type of grids (included): 6 - 720x540

    Type of external material: 304 AISI

    N° and type of basins: 60 - 360x165x125h

  • Energy Class (EU Reg. 2015/1094): D

    Yearly and daily energy consumption (EU Reg. 2015/1094): 2655kWh/year - 7kWh/24h

    Climate class (EU Reg. 2015/1094): Heavy Duty (5)

    Energy Efficiency Index-EEI (EU Reg. 2015/1094): 65.33

    Refrigerant type: R290

    GWP Index: 3

    Refrigeration power: 792 W

    Refrigerant weight: 135 g

  • Type of model (EU Reg. 2015/1094): vertical frozen

  • Control type: Electronic

    Compressor power: 3/4 hp

    Refrigeration power at evaporation temperature: -23.3 °C

    Operating temperature min.: -28 °C

    Operating temperature max.: -12 °C

    Operating mode: Ventilated

    Cooling unit: Built-In

Product Features

Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).
Tropicalized unit (43°C ambient temperature).
Large storage area suitable to contain 720x540 mm grids to improve net capacity.
IPX5 frontal water protection.
Large digital white-digit display with cabinet temperature display and setting and turbo frost cycle (to rapidly cool warm loads).
Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated. Up to two months of event are kept in memory.
Optimized airflow within the chamber guarantees uniformity of temperature on all grids.
Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.
Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.
Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.
Prearranged to fit RS485 port to facilitate connection to a remote computer and integrated HACCP systems.
Complies with main international certification bodies and is CE marked.
Prearranged for remote alarm.
Self closing and on site reversible left/right doors.
Low noise level.
This appliance is intended for use in ambient temperatures up to 40°C.
Stainless steel AISI 304 external panels (galvanized external back).
Refrigerant type: R290.
Inner cell with rounded corners, bottom pressed in only one piece.
Lockable door.
Stainless steel runners and supports easily disassembled.
Internal components removable without the use of tools to facilitate cleaning operations.
Pressed stainless steel door handle without joints gathering dust and dirt.
Easy access to the main components for maintenance.
Developed and produced in ISO 9001 and ISO 14001 certified factory.
Automatic heated door frame.
